Lab double stirred distillation glass reactor for chemical
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Chemical mixing stirring double layer glass biodiesel reactor
-
Stirring mixing agitated tank glass reactor with double receiving flask
-
Lab Crystallization Reactors Glass chemical reactor prices
-
Glass type double layer jacketed photochemical chemical glass reactor
-
Photochemical lab use explosion-proof glass jacketed quartz reactor
-
Distillation device pharmaceutical jcketed glass reactor
Product Description
Product Description
Lab double stirred distillation glass reactor for chemical
The kettle body is designed by double glazing glass reactor, the inner layer into the reaction solution to do the reaction was stirred interlayer can pass into the type of the cold heat source circulating heating or cooling the reaction can also be used in high temperature, low temperature, or vacuum experiment reflux and distillation of the reaction solution. It is the ideal equipment for primary and secondary schools of modern chemistry experiments, biopharmaceutical and synthesis of new materials.
Double layer jacketed glass reactor mainly used for distillation, extraction, widely used in medicine, food, chemical industry, fuel, etc. It is the ideal equipment for primary and secondary schools of modern chemistry experiments, biopharmaceutical and synthesis of new materials.
Contact Us For More Details
More Details Photos
Features
1. A full set of glassware with GG3.3 borosilicate glass production with good chemical and physical properties
2. Limit temperature of 250°C for high temperature experiments, and limit temperature of -60°C for low temperature experiments.
3. Titanium ring, new titanium alloy mechanical seal, sealing 0.098Mpa.
4. The PT100 temperature, and is a liquid crystal display. More accurate temperature measurement and more convenient.
5. Frequency control, AC induction motor. Constant speed, brushless, no spark, security and stability, and continuous work.
6. Quality 304 stainless steel all-inclusive PTFE stirring rod and a three-bladed propeller structure.
7. The bottom flanged discharge port, aluminum parts flange fixed container no dead ends.
Specification
Model | NB-100L |
Glass Material | GG-17 |
Frame Material | 304 Stainless steel |
Moving mode | Brake type universal corner wheel |
Reaction bottle capacity | 100L |
Jacketed Capacity | 18L |
Flanged out of the oil circulation port | Low feed high outlet |
Reaction bottle cover port | 6ports |
Discharger port distance to ground | 450mm |
Temp. range | -80-250°C |
Vacuum | 0.098Mpa |
Stirring speed | 0-450rpm |
Stirring diameter | 15mm |
Stirring power | 250W |
Voltage(V/Hz) | 220V/50HZ |
Dimension(mm) | 610*610*2400 |
Packing size(mm) | 1900*700*870 |
Packing weight（KG） | 125 |
Recommend Products
Send An Inquiry To Get The Latest Price
Packing & Delivery
Company Profile
Customer concerns
FAQ
Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem
Q2:OEM,ODM acceptable or not?
Absolutely Yes
Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...
Q4:Can we visit your factory online?
Absolutely no problem
Q5:Can online video inspection before shipment?
Absolutely no problem
Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem
Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements
Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.
After-sale service:
1.Warranty : 1 year
2.We supply free part for quality problem in warranty
3.Long life technical support and service
