Product Description
Product Description
Essential oil distiller 50l rotary evaporator with water chiller
Motor has the function of 10-120 RPM stepless speed regulation and automatic lifting, revolving consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-120 RPM range, it has reached the advanced level at home and abroad.
1 Quick and easy lifting mechanism
2 Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3 Vertical condensation system of high rate of evaporation
4 Vacuum sealing way
5 Automatic control temperature digital display
1 Quick and easy lifting mechanism
2 Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3 Vertical condensation system of high rate of evaporation
4 Vacuum sealing way
5 Automatic control temperature digital display
Specification
Model | NBRE-50L | NBRE-100L |
Glass meterial | GG-17 | GG-17 |
Holder material | Stainless steel | Stainless steel |
Pot shell Material | Spray anti-corrosion 710*620*700mm | Spray anti-corrosion 820*820mm |
Pot bravery | Stainless steel 550*320mm | Stainless steel 795*330mm |
Plate size | 804*574mm | 1600*830mm |
Evaporator flask | 50L flange mouth:Φ125mm | 100L flange mouth:Φ180mm |
Collect flask | 20L flange mouth:Φ60mm | 50L ball mouth:Φ40mm |
Vacuum degree | 0.098Mpa | 0.098Mpa |
Rotary speed | 0-110RPM | 0-110RPM |
Rotary power | 180W 220V/50HZ | 400W 220V/50HZ |
Heating power | 8KW 380V/50HZ | 12KW 380V/50HZ |
Heating temp. | 0-400℃ | 0-400℃ |
Temp. accuracy | ±1℃ | ±1℃ |
Lifting stroke | 180mm | 180mm |
Dimension | 1520*620*2470mm | 1700*850*2600mm |
Packing weight | 170kg | 400kg |
If You Need Other Model, Please Contact Us To Get More Information
More Details Photos
Application
Rotary evaporator is the necessary basic instrument for chemical industry, medicine industry, institutions of higher learning and scientific research laboratory and other units, it is the main means for manufacturing and analyzing experiments when they do extraction and concentration .
