Simple Operation Powder Coating Thickness Gauge Test Thickness of Plating and Coating

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Our Advantages

Product Description

The instrument is a type of portable measuring gauge, capable of measuring rapidly, nondestructively, and precisely the thickness of coating and cladding material. It is suitable for on site as well as for laboratory uses. Via the using of different probes, many sorts of measuring can be satisfied by the gauge. It can be applied comprehensively to manufacturing, metal processing and chemical profession as well as to commercial inspection. It is indispensable for the major of materials protection.

Specification

Specification	T100
Probe selection	Optional 10 probes
		F1(Paint/Plating/Fire-resistant layer and 10mm inner cover)
		Other probes: F400,F1/90°,F5,N400,N1,N1/90°,CN02,N10
Working principle	Magnetic induction and eddy current
Measurement accuracy	F1(±((1~2)%H+1)), F10(±((1~3)%H+1)), N1(±((1~2)%H+1))
Measuring range	F1(0~1250um), F10(0~10000um), N1(0~1250um)
Minimum curvature	F1(3mm),F10(10mm),N1(4mm),F400(1mm)
Minimum area	F1(Φ7),F10(Φ40),N1(Φ5),F400(Φ3)
Measurement method	Continuous measurement method, single measurement method
Statistics function	Mean, Large, Small, Tests,Standard Deviation
Calibration method	Single-point calibration,two-point calibration,and five-point basic calibration method to correct the system error of the probe
Storage function	Can store 495 measured values,with delete function:delete single suspicious data appearing in the measurement, or delete all data in the storage area for new measurement
Alam system	Linits can be set: automatic alarming for measured values outside the limits; with power undervoltage indication function; beepprompts during operation; with error prompt function, error prompts can be displayed on screen or by beeps
Shutdown method	Manual shutdown mode and automatic shutdown mode
Use environment	0~40℃/ humidity: 20%RH~90%RH Magnetic field-free environment
Power supply	Tow AA batteries
The standard configuration	Main unit 1 set/probe 1 set/ stan dard piece(5 pirces)/iron or aluminum base 1 piece/ 5 AA battery 2 sections/manual certificate warranty card 1 set

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided. One set is in one strong box.

Transaction process

Why Choose Us

Iwin testing equipment company is a high-tech enterprise focusing on the research and development, production and sales of engineering quality test and testing instruments.The company serves in the construction, the railroad, the highway, the water conservancy, the electric power, the university and the scientific research institute.To provide quality products, services and solutions for the industry. And establish a good long-term cooperative relationship with it.

"Build a craftsman's spirit and build a century-old enterprise" is the development concept we have been pursuing.

Product packaging

Our logistics

FAQ

1. who are we?
Iwin testing equipment based in Hebei, China, start from 2010.

Sell to Domestic Market(50.00%),South America(15.00%),Southeast Asia(10.00%),Mid East(10.00%),North America(5.00%),Africa(5.00%),Western Europe(5.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
We are professional manufacturer. Before shipping ,we test machine for three times to ensure client receive excellent machine.

3.what machines can you buy from us?

Metal test, Pile test, Soil test, Asphalt test, Concrete test, Cement test.

4. why should you buy from us not from other suppliers?
We mainly develop high-technology, high quality, energy saving and environmental-friendly building material products . We produce products according to international standard specification, we also can offer OEM service , like many kinds of couplers .

5. what services can we provide?
Delivery Terms: FOB,CFR,CIF,EXW,FAS,Express Delivery,DAF；
Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese, German, Arabic, French.
