Allosun EM2283 Automotive Voltage Test Wire Break Point Detector Little Fuse Current Test
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
Allosun EM9807 GFCI Socket Tester Household Electrical Safety Kit GFCI TESTER Outlet Tester
-
All-sun GK4 Voltage Tester Pen Household Safety Kit
-
Allosun GK9A Automotive Voltage Meter Car Circuit Volt Tester
-
ALL SUN GK7 Non-Contact Voltage Detector 70-1000V AC Voltage Tester Pen Blister Packaging LED Lights Voltage Measurement
-
Non Contact AC Voltage Tester, Pen Voltage Detector 100~1000 Vac at 50/60Hz With Built-in Flashlight and Vibrate Hint
-
ALL SUN GK16 AC Pen Non Contact Voltage Detect 50Hz-400Hz AC 5V-1000V Adjustable Sensitivity
Product Description
Products Description
All-sun EM2283 Automotive Voltage Test Wire Break Point Detector Little Fuse Current Test
This is a new model multifucntion automotive wire tester. It can be used to test DC Voltage, Wire break point detect and fuse current test. With new current measurement technology, user don't need to break the circuit being tested, only make the test lead contact two ends of the fuse being test, the current test can be done. This meter can be used to measure 0.1mV DC Voltage.
Specification:
Display: Max reading 9999
Power Supply:9V 6F22
IP Degree: IP20
Size:143*84*36mm
Weight:177g
DC Voltage Test:
Range:0.0V-50V
Resolution:0.1V
Precision:±(2%+2)
Max input voltage:100V
Break Point Test
Buzzer Sound when the resistance being test < 20Ω
Buzzer Not Sound when the resistance being test >40Ω
Buzzer Sound or not can not confirm when the resistance being test between 20Ω-40Ω
Fuse Current test:
Range:0.00A-50A (Standard)
0.00A-99.9A(Customize mode)
Resolution:0.01A
This is a new model multifucntion automotive wire tester. It can be used to test DC Voltage, Wire break point detect and fuse current test. With new current measurement technology, user don't need to break the circuit being tested, only make the test lead contact two ends of the fuse being test, the current test can be done. This meter can be used to measure 0.1mV DC Voltage.
Specification:
Display: Max reading 9999
Power Supply:9V 6F22
IP Degree: IP20
Size:143*84*36mm
Weight:177g
DC Voltage Test:
Range:0.0V-50V
Resolution:0.1V
Precision:±(2%+2)
Max input voltage:100V
Break Point Test
Buzzer Sound when the resistance being test < 20Ω
Buzzer Not Sound when the resistance being test >40Ω
Buzzer Sound or not can not confirm when the resistance being test between 20Ω-40Ω
Fuse Current test:
Range:0.00A-50A (Standard)
0.00A-99.9A(Customize mode)
Resolution:0.01A
