Features of Z28-80 threaded rod automatic threading machine:
1. Automatic feeding with adjuatable brackets
2. Speed is adjutable for different products
3. 54mm hole diamter for SKD11 thread rolling dies
4. Max. Rolling pressure is about 160KN
5. It is easy to operate and maintain the machine
6. CE
Technical parameter of thread rolling machine:
Model Z28-80 two roll threading machine
Rolling thread range Diameter 5-48mm
Roller size range Outdiameter 120-170mm
Hole 54mm Max width 100mm
Thread pitch 0.5-4mm
Spindle Angle ±8°
Max rolling pressure 160kn
Spindle drive power 4.0kw
Spindle RPM 37/46/63/79rpm
Hydraulic transmission power 2.2kw
Dimension 1520*1400*1450mm
Weight 1600kg
Any more questions for thread rolling machine, pls contact freely.
