Home > Electrical & Electronics > Variable-Frequency Drive > MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output

MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output

Name: MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output
Brand: Panasonic
SKU: 170780159

MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output thumbnail-1

MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output thumbnail-2

MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output photo-1

MADHT1507 Panasonic AC Servo Driver Current Detector Signal Output photo-2

US$ 1 - 1000000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Brand Name:

Panasonic

Place of Origin:

Japan

Model Number:

MADHT1507

Contact Supplier Request Quote Chat Now

Huizhou Linchuang Technology Co ., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

5 days

Product Details
Company Profile
Contact Us

Brand Name Panasonic

Place of Origin Japan

Model Number MADHT1507

Motor Type AC Motor

Brand:	Panasonic	Model Number:	MADHT1507
Country Of Origin:	Japan	Type:	Industrial Servo Drives
Series:	A5 Series	Frequency Response:	2.3 KHz
Power Device Max. Current Rating:	10A	Supply Voltage:	Single/3-phase 200 V
Current Detector Current Rating:	7.5A
High Light:	electric servo drive,ac servo drive

Panasonic Industrial AC Servo Drives MADHT1507 200W 200-240VAC 240V

Description

Series	MINAS A5
Package	Box
Part Status	Active
Type	Module
Motor Type	Servo
Control / Drive Type	Servo AC
Voltage - Load	240V
Current - Output	10A
Voltage - Supply	200 ~ 240VAC
Interface	RS-232, RS-485, USB
Mounting Type	Chassis Mount
Operating Temperature	0°C ~ 55°C
Features	-
For Use With/Related Products	MINAS A5 Series
Weight	1.7 lbs (771.1 g)
Number of Motors	1
Wattage - Load	200W

Specifications

Item	Specifications
Input power: Main circuit	Single/3-phase 200 to 240V +10% -15% 50/60 Hz
Input power: Control circuit	Single phase 200 to 240V +10% -15% 50/60 Hz
Encoder feedback	17-bit (131072 resolution) absolute encoder, 7-wire serial 20-bit (1048576 resolution) incremental encoder, 5-wire serial
External scale feedback	A/B phase, homing signal differential input. Serial communication is also supported.
Parallel I/O connector: Control signal Input	General purpose 10 inputs The function of general-purpose input is selected by parameters.
Parallel I/O connector: Control signal Output	General purpose 6 output The function of general-purpose output is selected by parameters.
Parallel I/O connector: Analog signal Input	3 inputs (16-bit A/D : 1 input, 12-bit A/D : 2 inputs)
Parallel I/O connector: Analog signal Output	2 outputs (Analog monitor: 2 output)
Parallel I/O connector: Pulse signal Input	2 inputs (Photo-coupler input, Line receiver input)
Parallel I/O connector: Pulse signal Output	4 outputs (Line driver: 3 output, open collector: 1 output)
Communication function	USB, RS232, RS485
Communication function: USB	USB interface to connect to computers for parameter setting or status monitoring.
Communication function: RS232	1:1 communication
Communication function: RS485	1: n communication (max 31)
Regeneration	No built-in regenerative resistor (external resistor only)
Control mode	Switching among the following 7 mode is enabled, (1) Position control, (2) Speed control, (3) Torque control, (4) Position/speed control, (5) Position/Torque control, (6) Speed/Torque control, (7) Full-closed control
