10/100/1000M Ethernet to Fiber Media Converter With Dual SFP Slot and 2 RJ45 Port
- T/T Credit Card
You May Like
Product Description
10/100/1000M ethernet to fiber media converter with dual SFP Slot and 2 RJ45 port
1.Description
1).IEEE802.3u 1000Mbps Fast Ethernet SFP Converter supports two types media for network connection such as 10/100/1000Base-TX and 1000Base-FX.
2).The media converter is designed with a switch controller and buffer memory that connects two types segments to operate smoothly. With internal or external power unit, it provides good stability and reliability.
2.SFP Technical Specifications
| 1000Base-FX-2 | 1000Base-FX-20 |
Connector type | LC | LC |
Fiber type | Multi-mode | Single-mode |
Wavelength | 1310nm | 1310nm |
Max Distance | 2Km | 20Km |
Min TX PWR | -20.0dBm | -14.0dBm |
Max TX PWR | -14.0dBm | -8.0dBm |
Sensitivity | < -30dBm | < -30dBm |
Link Budget | 10.0dBm | 16.0dBm |
1000Base-FX-60 | 1000Base-FX-100 | |
Connector type | LC | LC |
Fiber type | Single-mode | Single-mode |
Wavelength | 1310nm | 1550nm |
Max Distance | 60Km | 100Km |
Min TX PWR | -5.0dBm | -3.0dBm |
Max TX PWR | 0dBm | 3dBm |
Sensitivity | < -35dBm | < -35dBm |
Link Budget | 30.0dBm | 32.0dBm |
3.Technical Specifications
Standerds: IEEE 802.3/802.3u 10/100/1000Base-TX;
1000Base-FX
UTP Cable: Cat.5 cable up to 100m.
Fiber Cable:
Multi-mode: 50/125,62.5/125µm
Singie-mode: 9/125µm .
TP Flow Control: NWay auto-negotiation
Fiber Flow Control: NWay at full-duplex mode
Power Requirement: 220V(175-260V)AC,50Hz
Ambient Temperature: 0 ~ 50℃
Humidity: 5% ~ 90%
dimensions:External: 26×70×93mm
Internal Power:30×110×140mm(H×W×D)
