SFP+ SR TRx850nm 300m sfp+ module
Description
1.The transmitter converts 10Gbit/s serial PECL or CML electrical data into serial optical data compliant with the 10GBASE-SR standard.
2.An open collector compatible Transmit Disable (Tx_Dis) is provided. A logic “1,” or no connection on this pin will disable the laser from transmitting.
3.A logic “0” on this pin provides normal operation.
4.The transmitter has an internal automatic power control loop (APC) to ensure constant optical power output across supply voltage and temperature variations.
5.TX_Disable is a module input contact. When TX_Disable is asserted high or left open, the SFP+ module transmitter output shall be turned off.
6.This contact shall be pulled up to VccT with a 4.7 kΩ to 10 kΩ resistor
Features
Optical interface compliant to IEEE 802.3ae 10GBASE-SR
Electrical interface compliant to SFF-8431
Hot Pluggable
850nm VCSEL transmitter, PIN photo-detector
Maximum link length of 300m on 2000MHz/km MMF
Operating case temperature: 0 to 70°C
Low power consumption
Specification
Optical characteristics
Parameter |
Symbol |
Min. |
Typical |
Max |
Unit |
Notes |
Transmitter | ||||||
Center Wavelength |
λt |
840 |
850 |
860 |
nm |
|
RMS spectral width |
Pm |
- |
- |
Note 1 |
nm |
|
Average Optical Power |
Pavg |
-6.5 |
- |
-1 |
dBm |
2 |
Extinction Ratio |
ER |
3.5 |
- |
- |
dB |
3 |
Transmitter Dispersion Penalty |
TDP |
- |
- |
3.9 |
dB |
|
Relative Intensity Noise |
Rin |
- |
- |
-128 |
dB/Hz |
12dB reflection |
Optical Return Loss Tolerance |
|
- |
- |
12 |
dB |
|
Receiver | ||||||
Center Wavelength |
λr |
840 |
850 |
860 |
nm |
|
Receiver Sensitivity |
Psens |
- |
- |
-11.1 |
dBm |
4 |
Stressed Sensitivity in OMA |
|
- |
- |
-7.5 |
dBm |
4 |
Los function |
Los |
-30 |
- |
-12 |
dBm |
|
Overload |
Pin |
- |
- |
-1.0 |
dBm |
4 |
Receiver Reflectance |
|
- |
- |
-12 |
dB |
|
- Quality system of ISO900,CE,FCC,ROHS registration
- Manufacture system
- R&D system
- Purchasing system
- Prompt delivery and remarkable services
- Reasonable prices
- Accept orders according to customer's demands
- Rich experience of OEM & ODM co-operation
- Shipment,payment and delivery
We sincerely invite all interested buyers to visit our company and contact us directly for further information, we will reply you as soon as possible!!!
