Generic compatible 10GB Xenpak SR 300m 850nm VCSEL 10g Xenpak modules
1.Description
1). Rollball’s xenpak transceiver module is a highly integrated, Serial optical transponder module for high-speed, 10Gbit/s data transmission applications. 4×3.125Gbps Ethernet Signal Input by XAUI Interface.An integrated Coder / Decoder and multiplexer/ demultiplexer (SERDES: Serializer / Deserializer).
2). Designing for 10GBASE-SR/LR/ER/ZR Transmission with an uncooled directly modulated 850nm VCESE/1310nm DFB/1550nm DFP Laser. The transponder operates within a wide case temperature range of 0°C to +70 °C and offers optimum heat dissipation and excellent electromagnetic shielding which enables high port densities for 10 GbE systems. 3). A 70 pin electrical connector and a duplex SC connector optical interface assure that connectivity is compliant to the XENPAK MSA Rev.3.0.
2.Applications
10GBASE-SR/LR/ER/ZR 10G Ethernet
3.Features
1).SC duplex Optical connector
2).Compatible with XENPAK MSA Rev.3.0
3).Support of IEEE802.3ae 10GBASE-SR/LR/ER/ZR
4).Complete metal housing for electromagnetism protection
5).Transmission Distance up to 80km(SMF)
6).Uncooled directly modulated DFB Laser
7).Temperature Range –5 to 70°C
8).Adaptable Power Supply (APS:+1.2V)
9).Hot pluggable 70-pin connector with XAUI electrical interface
10).Management and control via MDIO 2-wire interface
11).Compatible with RoHS
4.Product list
Part Number |
Specification |
|||||
Data Rate |
Wavelenth |
Fiber |
Distance |
Temp. |
Source |
|
XENPAK SC Duplex Port | ||||||
RXENPAK-85192-SRD |
10Gb/s |
850nm |
MM |
300m |
0~70 |
VCSEL |
RXENPAK-31192-LRD |
10Gb/s |
1310nm |
SM |
10km |
0~70 |
DFB |
RXENPAK-55192-ERD |
10Gb/s |
1550nm |
SM |
40km |
0~70 |
DFB |
RXENPAK-55192-ZRD |
10Gb/s |
1550nm |
SM |
80km |
0~70 |
DFB |
