Home > Products > Fiber Optic Splitter > Same Specification 1x8 Huawei Fiber Optic Splitter

Same Specification 1x8 Huawei Fiber Optic Splitter

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Same specification 1x8 huawei fiber optic splitter

1.Description

Rollball offers both tree and star type inline couplers/splitters. They provide a reliable solution to split/combine signals. The splitting ratio ranges from 1x2 to 1x4 ports for tree couplers, and from 2x2 up to 4x4 for star couplers. Available in single, dual, and tripple wavelength windows(1310/1490/1550nm).

2.Feature

1).Low Insertion loss

2).Low PDL

3).Environmentally stable

4). Good Thermal Stability

3.Specification

	Nx4 N = 1,2,4	Nx8 N = 1,2,8	Nx16 N = 1,2	Nx32 N = 1,2
Operation Wavelength(nm)	1310, 1490 and 1550nm
Banwidth(nm)	1310±40,1490±10 and 1550±40
Insertion loss(db)	≤7.2	≤10.8	≤14.4	≤17
Typical Insertion loss(db)	0.3	0.45	0.6	0.75
PDL(db)	≤0.3	≤0.4	≤0.5	≤0.6
Directivity(db)	≥55
Operation Temp	-40 to +85 degree
Lead length	1meter, Customized on client’s request
Lead type	900um, 2.0mm, 3.0mm loose tube
Package dimension

4.Product list

tray plc splitter

No.	Item	Spec
1	FBT Splitter	1*2, Wavelength 1310/1490/1550 +- 40nm, In/output 0.9 jacket fiber cable, steel tube type
2	FBT Splitter	1*2, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, ABS Box Module
3	FBT Splitter	1*4, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, ABS Box Module
4	FBT Splitter	1*8, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, ABS Box Module
5	FBT Splitter	1*16, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, ABS Box Module
6	FBT Splitter	1*32, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, ABS Box Module
7	FBT Splitter	1*2, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, 19" rack mount box, SC/LC port
8	FBT Splitter	1*4, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, 19" rack mount box, SC/LC port
9	FBT Splitter	1*8, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, 19" rack mount box, SC/LC port
10	FBT Splitter	1*16, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, 19" rack mount box, SC/LC port
11	FBT Splitter	1*32, Wavelength 1310/1490/1550 +- 40nm, In/output 2.0/3.0mm jacket fiber cable, 19" rack mount box, SC/LC port

Our Strength & Quality Assurance

*Factory

*Certifications

*Producting & Testing Equipment

Payment & Shippment & Delivery

1.Payment

2.Shipment:by Sea,by Air,by Express:DHL/UPS/Fedex/EMS/TNT etc

3.Deliverty: 3-5 days after payment dowm.
