PG-ISM500
Fiber Optic Microscope / Inspector USB Version
Special Features:
• Included Pass/Fail Software according to IEC 61300-3-35
• Very usefully device to inspect Fiber Optic Connectors in field
• One handed operation
• Simply Portable
• Low Price but good capacity
• Available several adaptor types Tips (Both Female / Male Tip)
• Electric Power by USB
• Save Tested Analysis Report on PC by USB device
• Control the display size
• Easy and usage by setup
• Anti-slip Grip design and Easy Focus
• Complied with RoHS
• CE/FCC approved
Specifications:
|
Brand Name |
|
HUXScope-UE |
|
Magnification |
|
260~400X (Digital) |
|
Filed of Vision |
|
400um x 300um |
|
Focus |
|
Manual, Maximum 2mm in and out |
|
CCD |
|
1/4” CMOS |
|
Power Supply |
|
Computer USB Electric Power |
|
Software |
|
For Windows 8, 7 and XP |
|
Dimension |
Handset (without Tip) |
185mm (L) x 24mm (T) |
|
Weight |
150g |
|
|
USB |
|
USB 2.0 |
Standard Package:
1 Handset (included USB)
1 Software
1 Tip for female SC/PC and FC/PC
1 Tip for female LC/PC
1 Manual
[Remark] Female Tip is for ferrule inside of adaptor and Male Tip is for patchcord ferrule.
