            professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle

professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle

 professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle

Product Description

 Main Features of 5 axis cnc router

 Main Features:

1

SYNTEC controlling system, steady performance, powerful function ,easy

operation



2

Well-known Italy HSD air cooling spindle ,high precision, long life time, steady

working



3

Well-designed whole cast steel lathe bed, well welded ,no distortion for whole

structure



4

Movable table structure, working more steadily than that with moving gantry,

especially while engraving waved plate



5

Adopted Japan THK linear square guide rail system, working steadily, high

precision ,long life time



6

Diversified controlling. It can control working speed, air line speed and cuter

setting .



Parameters of 5 axis cnc router



Number

Item



Parameter

1

X Y Z C A axis working area

1500*3000mm

213degree*120degree

2

Table size

2620*8440*1800mm

3

Positioning accuracy

±0.01mm

4

Reposition accuracy

±0.01mm

5

Table

Moveable Milling steel(with T-slot) Italy HSD 9kw ATC spindle

6

Frame

Cast iron(heavy steel)

7

Drive system X axis

Rack and pinion

8

Drive system Z ,Y axis

Ball screw

9

Max power consumption

14.2kw

10

Max velocity

25000mm/min

11

Max working speed

15000mm/min

12

Spindle speed

0-24000rmp

13

Work mode

SYNTEC servo

14

Working voltage

AC380v(220v)

15

Command language

G code

16

Interface

CF card, Ethernet

17

Operating system

SYNTEC

18

Flash memory

512M

19

X-Y resolution

0.02/300mm

20

Software

UGS, Alpha Cam,Becam,Type3,UcancamV9

21

Running

Temperature :0 °C-45°C

22

Packing size

3300*2200*2000mm(in parts)

23

Net weight

6550kg

24

Gross weight

7400kg



Main parts used on  5 axis cnc router



1.Italy HSD air cooling ATC spindle on 5 axis cnc router



professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle



2.Advanced SYNTEC control system on 5 axis cnc router



professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle



3.Japan YASKAWA servo motor and driver on 5 axis cnc router



professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindleprofessional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle



4.Heavy duty steel casting body structure on 5 axis cnc router



professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle



 Applicable Industries



1

Mold industry: metalloid mould, especially suitable for automotive foam

mould, wooden train/ship/car model and so on

  5 axis cnc router

2

Instrument industry: shaping lager instrument and engraving on three-dimensional surface.

  5 axis cnc router

3

Furniture industry: wood furniture, wooden jewelry box, wood carving



Some work samples of 5 axis cnc router

professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle

professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindleprofessional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindleprofessional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindleprofessional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle

FAQ                                                                                         -------- SENKE --------



Q1: I knew nothing about this machine, what kind of machine i should choose?
     Very easy to choose. Just tell us what you want to do by using CNC router, then let us give you perfect solutions and suggestions.
Q2: When I got this machine, but I don’t know how to use it. What should I do?
     We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or skype and e-mail.
Q3: If some problems happen to this machine during warranty period, what should I do?
    We will supply free parts during machine warranty period if machine have some problems. While we also supply free life long after-sales service. So any doubts, just let us know, we will give you solutions.
Q4: Before sending me an inquiry on our cnc router, it is better for you to provide me the following information
1)Your metal or non-metal material size. Because in our factory, we have different models according to working area.
2)Your materials:Metal/Acrylic/plywood/MDF?
3)You want to engrave or cut?

professional 5 axis ATC cnc carving machine for engraving milling wood mold bath tub with 9kw ATC spindle
