Electromagnetic Sealing Machine

Electromagnetic sealing machine, structure and principle;

Fully automatic electromagnetic induction aluminum foil sealing machine system introduces American technology and imported integrated circuit, which has the advantages of small size, strong power, short bonding time, high speed, high strength and reliable performance. And the product is not directly contacted with the bottle, so that the contents in the bottle are not affected. This series of equipment has been appraised by relevant departments, and its electromagnetic radiation intensity conforms to the national safety standards, and it is absolutely harmless to human body.

Electromagnetic aluminum foil sealing machine is based on the principle of electromagnetic induction. The aluminum foil on the bottle mouth instantly generates high heat, and then it is fused on the bottle mouth to achieve the sealing function. It has good moisture-proof, anti-virus and anti-counterfeiting effects, and can prolong the shelf life of goods. It is suitable for ideal packaging equipment in medicine, pesticide, daily chemical, food, beverage, health care products, lubricating oil and other industries. The container can be made of polyethylene (PE), polypropylene (PP), polyester (PET), polystyrene (PS),ABC glass, etc., and can't be used in metal bottles and caps. This machine uses imported stainless steel plates for stamping and welding.

Performance features:

　　1 。 Type of equipment: Automatic online high-speed sealing machine, matched with or embedded in assembly line, suitable for mass production of assembly line products.

　　2 。 Cooling system: The radiator is forced to water-cool by internal circulation, with strong wind cooling. Its cooling performance is more than 20% stronger than that of other similar sealing machines, so that the main machine can work stably for a long time, with high sealing efficiency, good sealing quality and adjustable sealing height. It can be applied to bottles of various heights.

　　3 。 Sealing speed: 4000ml: 20-60 bottles (barrels)/min 1000ml: 30-80 bottles (barrels)/min 500ml: 40 -120 bottles (barrels)/min

100ml: 50 -260 bottles (barrels)/min

50ml: 100-300 bottles (barrels)/min

　　4 。 Water pressure control: automatic power-off function when the cooling water level decreases or the circulating water is blocked or blocked.

　　5 。 Automatic protection: when the whole machine is over-temperature, over-current and over-voltage, the high frequency will automatically stop heating to realize the protection function 6. Water level control: when the water tank is short of water, it will automatically flash and alarm, and power off automatically.

　　7 。 Automatic start and stop of the equipment, simple operation, simple installation and control of the equipment, stable and reliable performance Note: When the indoor temperature drops below zero, the cooling water must be replaced with antifreeze.

Technical parameters:

Work     Rate:       3.6KW

Operating power:       80KHZ

Sealing diameter::   10-160mm

Production capacity:     0-300P/ min

Cooling system:   Internal self-circulating axial flow fan with strong wind-water cooling power:   Source:         AC220/15A body:   Product:       600*450*1150

Weight of the machine: 100kg
