Introduction of Automatic Tonnage Bag Packaging Machine: Automatic Tonnage Bag Packaging Machine, also known as Automatic Tonnage Bag Packaging Machine, Automatic Tonnage Bag Packaging Scale and Automatic Tonnage Bag Packaging Scale, is a kind of automatic Tonnage Bag Packaging Equipment. Automatic Tonnage Bag Packaging Machine overcomes the shortcomings of manual bag loading (bag hanging) of Tonnage Bag Packaging Machine (Tonnage Bag Packaging Scale, Big Bag Packaging Scale), and realizes automatic bag loading, material weighing and filling of Tonnage Bag. Automatic ton bag packaging machine can be applied to any production line that needs big bag packaging, and can perfectly replace semi-automatic manual bag loading ton bag packaging machine. Both granular materials and powder materials can be transported in automatic boxes by using automatic ton bag packaging machine. With the increase of labor cost, the application and promotion scope of automatic ton bag packaging machine is increasing.
Function of automatic full-ton bag packaging machine
1. Automatic transportation and analysis of tons of bags.
2. Automatic loading of tons of bags.
3. Automatic lifting of one-ton bags.
4. Automatic inflation and bag expansion
5. Automatic packing of materials
6. The gas in the packaging bag is automatically discharged.
7. Automatic heat sealing of the opening of the ton bag.
8. Transportation of finished products in tons of bags
9, production date, batch number and other data automatic code printing.
10. Automatic finishing of the bag mouth.
11. The adjustment of the strap at the mouth of the ton packing bag is beneficial to the lifting, palletizing and loading of forklifts or cranes.
During the working process of the automatic full-ton bag packing machine, tons of bags are rolled into a roll according to the specifications of 150 bags. The whole bundle of bags is manually put into the bag frame, and the empty bags move forward on the conveyor. When the bag mouth reaches the appropriate position, the sensor sends the signal of the bag in place to the general control PLC, and the PLC gives an instruction. The upper and lower suction cups suck the bag mouth and pull it away. The manipulator clamps the bag mouth, moves the bag forward and lifts it, and puts the bag into the blanking opening. At the same time, after receiving the successful signal of bagging, the weighing system puts the materials into tons of packaging bags according to the set gravity to complete the filling of the materials. After filling, the bag supporting mechanism stretches the bag mouth, the ultrasonic sealing machine sews the bag mouth, the auxiliary mechanism arranges the bag mouth, and the posture adjusting mechanism lifts the bag strap and adjusts the strap direction, which is beneficial to the automatic stacking of the subsequent stacking system. At this point, the system completes the full-automatic filling process of one ton bag.
Guide to the selection of automatic full-ton bag packaging machine
1. Confirm material characteristics.
2. Determine the installation position and space size.
3. For powder materials, a dust removal system is required.
4. Agreement on packaging accuracy and packaging speed of full-automatic ton bag packaging machine
5. The requirements and limitations of the subsequent palletizing system on the position, height and direction of the strap of the full-automatic ton bag packaging machine.
6. If explosion-proof is required, it is necessary to determine the explosion-proof level.
7. Determine the gas consumption of equipment.
8. Determine the packaging bag size according to the material specific gravity and material performance.
