automatic brick machine/fly ash brick machine/automatic brick making machine for bangladesh

Name: automatic brick machine/fly ash brick machine/automatic brick making machine for bangladesh
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

HENGYI Interlocking brick maker

Product Detailes

QT4-15 Interlocking brick maker

Our Interlocking brick maker are with simple and compact structure, convenient operation and easy maintenance. It demands litter manpower and investment, but makes high output and quick ROI (return on investment). Especially suitable to produce standard bricks, hollow bricks, pavers, etc. The strength of which is higher than that of clay bricks. Various types of blocks can be produced with different molds. Therefore, It is an ideal choice for enterprises with small investment.

Main Parts&Technolog

Detailed Specs of Interlocking brick maker

Main Specs:
Environmental protection				Confirms to the international environmental protection standard
General power				23KW
Average power consumption				20KW/h
Average water consumption				9T/day
Land area				3000m2 totally
Technical Specifications:
Output capacity per mould	Standard brick		240x115x53mm			26pcs/mould
	Porous brick		240x115x90mm			9pcs/mould
	Hollow brick		390x190x190mm			4pcs/mold
Output capacity per hour	Standard brick		240x115x53mm			4300pcs/hour
	Porous brick		240x115x90mm			2000pcs/hour
	Hollow brick		390x190x190mm			600pcs/hour
Hollow brick		390x190x190mm			4800pcs
Cycle time	22s
Power	19.5kw
Weight	3T
Area	2500m2
Workers	5-8
Dimension	295021501600 mm
Pallet size	85055030mm
Suggested pallets numbers	500-800pcs
Equipment list:
Name of the item		Quantity			Remarks
decorative concrete manual block making machine in kenya for sale		1
Mixer		1			JW350
Belt conveyor		1			8m
Free mould		1
Pallets		1000pcs			Upon ur request
Block trolley		1

Production Flow

Full Automatic Production Flow chart:

Associated equipments:

	Stacking Machine(Double) Brand: HENGYI Motor drives the chain sprocket rotation,thereby lifting chain,and pallets.it is stopped by inductor.The motor has the function of brake,can stop at any time
JS500 Concrete Mixer Brand: HENGYI Double mixture axes, the speed of mix ,will be approved to a large degree, and the Large particles can easily be stirred We use 2.5cm thickness pad, to prevent the body steel get hurt, and customer only need to change the iron pad
	PLD1200 Batching Machine Brand: HENGYI The electronic weighing, microcomputer control, digital display, wired remote control operation, has the advantages of accurate weighing, high precision, high speed, strong control function.
50T Cement Silo Brand: HENGYI Mainly to used for storing cement, connecting with screw conveyor to transport cement to the PLD batching machine.
