Front Dozer 165HP Motor Grader GR165 Rear Ripper
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale 135HP Small Motor Grader GR135 In PhilippinesNegotiableMOQ: 1 -
2022 Evangel China Motor Grader GR215 With Blade and RipperNegotiableMOQ: 1
-
2022 Evangel GR2153 Gr215 Motor Grader China 215hp 180hp GR163 GR180 Motor GraderNegotiableMOQ: 1
-
2022 Evangel Motor Grader 180hp Motor Grader GR180 GR1803 Sale With Cheap PriceNegotiableMOQ: 1
-
Road Mini Vibratory Roller 4 Ton Double Drum Road Roller Compactor XMR403NegotiableMOQ: 1
Products Description
Front Dozer 165HP Motor Grader GR165 Rear Ripper
The motor grader is mainly used for ground leveling, ditching, slope scraping, bulldozing, scarification, snow removal for large areas such as highway, airports, farmlands etc. It is the necessary construction machinery for national defense construction, mine construction, urban and rural road construction and water conservancy construction, farmland improvement and so on.
Advantages and Highlights:
1. The GR165 adopts Dongfeng 6BTA5.9-C180-II turbocharged diesel engine, which has large output torque and power reserve coefficient and low fuel consumption.
2. The torque converter has a large torque coefficient, a high efficiency, a wide effective area, and a good joint operation
characteristic with the engine.
3. Rear axle main drive is equipped with "NO-SPIN" without self-locking differential. When one wheel slips, the other wheel can still transmit its original torque.
4. The service brake is a dual-circuit hydraulic brake system that acts on the two rear wheels of the grader and is safe and
reliable.
5. The sealed cab is used to configure the air conditioning system. The interior parts are sleek and compact plastic parts, which fully reflects the needs of ergonomics.
Advantages and Highlights:
1. The GR165 adopts Dongfeng 6BTA5.9-C180-II turbocharged diesel engine, which has large output torque and power reserve coefficient and low fuel consumption.
2. The torque converter has a large torque coefficient, a high efficiency, a wide effective area, and a good joint operation
characteristic with the engine.
3. Rear axle main drive is equipped with "NO-SPIN" without self-locking differential. When one wheel slips, the other wheel can still transmit its original torque.
4. The service brake is a dual-circuit hydraulic brake system that acts on the two rear wheels of the grader and is safe and
reliable.
5. The sealed cab is used to configure the air conditioning system. The interior parts are sleek and compact plastic parts, which fully reflects the needs of ergonomics.
Specification
Item |
GR165 |
||||
Basic parameters |
Engine model |
6BTA5.9-C180-Ⅱ |
|||
Rated power/speed |
130kW/2200rpm |
||||
Overall dimension (standard) |
8900x2625x3470 |
||||
Total weight (standard) |
15000kg |
||||
Tire specification |
17.5-25 |
||||
Ground clearance (front axle) |
430mm |
||||
Tread |
2156mm |
||||
Space of front and rear axles |
6219 mm |
||||
Performance parameters |
Forward velocity |
5,8,11,19,23,38km/h |
|||
Reverse speed |
5,11,23km/h |
||||
Tractive effort f=0.75 |
77kN |
||||
Maximum gradeability |
25% |
||||
Tire inflation pressure |
260kPa |
||||
Working system pressure |
16MPa |
||||
Transmission pressure |
1.3—1.8Mpa |
||||
Working parameters |
Maximum steering angle of front wheel |
±50° |
|||
Maximum slant angle of front wheel |
±17° |
||||
Maximum oscillating angle of front axle |
±15° |
||||
Maximum oscillating angle of equilibrium box |
±15° |
||||
Maximum steering angle of frame |
±27° |
||||
Minimum turning radius |
7.3m |
||||
Scrape knife |
Maximum lift height |
450mm |
|||
Maximum cutting depth |
500mm |
||||
Maximum tilt angle |
90° |
||||
Cutting angle |
28°—70° |
||||
Angle of revolution |
360° |
||||
Length & chord height |
3660x610mm |
||||
Oil filling amount |
Coolant |
50L |
|||
Fuel tank |
280L |
||||
Engine |
24L |
||||
Transmission |
38L |
||||
Hydraulic oil |
110L |
||||
Drive axle |
28L |
||||
Balancing box |
46 L |
||||
