China Brand New Mini Crawler Crane 50 Ton XGC55 for Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2004
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Zoomlion 100ton New Mobile Truck Mounted Crane Price Xct100/ztc1000/stc1000NegotiableMOQ: 1 -
Zoomlion 80 Ton Crane ZTC800E552 Mobile Truck Crane for SaleNegotiableMOQ: 1
-
Zoomlion Crawler Crane 50 Ton 55 Ton Crane ZCC550V SaleNegotiableMOQ: 1
-
Cheap Price ZOOMLION 55 Ton Hydraulic Truck Crane ZTC550NegotiableMOQ: 1
-
ZOOMLION 50ton Mobile Truck Crane ZTC500ANegotiableMOQ: 1
Contact Way
Annie Li
Sales Manager
Wechat/Mobile/Whatsapp: +86 138 1769 0558
Email: Annie at
Products Description
1. Optimized hydraulic system design * Integrated design to reduce failure points, while reserve open space for
assembly/disassembly and maintenance.
* Use of highly integrated main valve, with the functions of multi-com-plex operation, control of combined flow, high/low
speed selection, to ensure operation efficiency.
* Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.
2. Main/ auxiliary hook one-key-switch-over function
*One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.
3. Universal and modular design
*common platform products with fixed jib, single top, both-sided counterweight, luffing mechanism,hydraulic pump and main valve block can achieve universal and interchangeable use, greatly reduce purchase, transport and maintenance costs.
assembly/disassembly and maintenance.
* Use of highly integrated main valve, with the functions of multi-com-plex operation, control of combined flow, high/low
speed selection, to ensure operation efficiency.
* Optional unique independent bypass filtration in the industry, strong magnetic adsorption device, strengthened hydraulic system filtration, and anti-emulsifying ability.
2. Main/ auxiliary hook one-key-switch-over function
*One-key-switch is used to easily achieve main/auxiliary hook switch-over, for wider range of applications.
3. Universal and modular design
*common platform products with fixed jib, single top, both-sided counterweight, luffing mechanism,hydraulic pump and main valve block can achieve universal and interchangeable use, greatly reduce purchase, transport and maintenance costs.
Product Paramenters
Items |
Unit |
Parameter value |
Max. rated lifting load of main boom |
(t) |
55 |
Max. rated lifting load of fixed jib |
(t) |
11.4 |
Max. lifting load moment |
(t.m) |
203.5 |
Max. rated lifting load of boom single pulley |
(t) |
6 |
Main boom length |
(m) |
13~52 |
Main boom luffing angle |
(°) |
-3~80 |
Fixed jib length |
(m) |
7~16 |
Max. size of single unit for transport (L×W×H) |
(m) |
12.04×3.45×3.36 |
Installation angle of fixed jib |
(°) |
10,30 |
Max. single line speed of hoist system |
(m/min) |
125 |
Max. single line speed of main luffing system |
(m/min) |
87/78 |
Max. slewing speed |
(r/min) |
2.45/2.2 |
Max. travel speed |
(km/h) |
1.37/1.22 |
Gradeability |
(%) |
30 |
Average ground pressure |
(MPa) |
0.06 |
Model |
- |
SC7H210.1G3/QSB6.7 |
Engine power |
(kW) |
155/153 |
Emission |
- |
National III stage/Europe III |
Crane overall mass |
(t) |
46.3(Main hook,13m boom) |
Max. weight of single unit for transport |
(t) |
28.6 |
