Zoomlion crawler crane 50 ton 55 ton crane ZCC550V sale
Contact person:Jin Zou
Mobile/Whatspp/Wechat/Skype:+86 17707042688
Email:jin at
Products Description
ZCC550 hydraulic crawler crane is small tonnage products, the product has a main boom, fixed jib two basic conditions, can be
widely used in urban construction and reconstruction, roads, railways, bridges, ports, energy, industrial plant and equipment
installation and handling and other operations.
Specification
Items
Units
Values
Remark
Maximum weight × amplitude
t × m
55 × 3.7
Fixed jib maximum weight
t
5.5
With a jib boom conditions Maximum weight
t
27.3
Main boom length
m
13 to 52
Fixed jib length
m
6 to 15
Fixed jib boom +
m
43 +15
Change the angle
°
30 to 81
Fixed jib mounting angle
°
10,30
Speed of single rope on drum
Main lifting
m / min
120
Auxiliary lifting
m / min
120
Change
m / min
56
Swing speed
rpm
0 to 2.1
Walking speed
km / h
0 to 1.6
Gradeability
%
30
Basic boom, counterweight placed in front of the
Ground pressure
MPa
0.069
Weight
t
51
With basic boom
Counterweight
t
18
Total Dimensions L × W × H
mm
12800 × 4600 (3300) × 3140
With Renzi Jia, bottom arm
Engine
Model
WP6G190E26
Weichai Power
Rated power / speed
kW / rpm
140/1900
Maximum output torque / speed
Nm / rpm
830/1300
Track gauge × length × Width of shoe grounding
mm
2540 × 5000 × 760
Track Frame retracted
mm
3840 × 5000 × 760
Track Frame extended
