China good performance 1.05-1.25m3 bucket 26 ton crawler excavator XE265C with Japan imported engine
Product Description
XE265C 26 ton rc construction excavator for sale.
1,The overall layout and the axle load distribution are more reasonable to achieve better traveling stability and the maximum traveling speed is up to 40km/h to realize faster site transfer speed.
2,The domestic leading hydraulic system distribution technology features high energy-saving and efficiency.
3,The highest breakout force on the loading end is leading the industry by 15%~20% compared with like models.
4,The advanced structure and hinge points on the digging end and the industry's largest rotating angle of the bucket ensure strong soil holding capacity.
| Unit | Parameters | ||
| Model | Operating weight | kg | 25500 |
| Bucket capacity | m³ | 1.05-1.25 | |
| Engine | Engine model | / | ISU-ZU CC-68G1TRP-05 |
| Direct injection | / | √ | |
| 4×strokes | / | √ | |
| Water cooling | / | √ | |
| Turbocharging | / | √ | |
| A/A Air-air intercool | / | √ | |
| Cylinders | / | 6 | |
| Output power of engine | Kw/rpm | 135.2/2150 | |
| Max.torque/engine | N.m/rpm | 637/1800 | |
| Displacement | L | 6.494 | |
| Mian pertormance | Travel speed | km/h | 5.9/4.0 |
| Slewing speed | r/min | 11.3 | |
| Gradient capability | ° | ≤35° | |
| Ground pressure | kPa | 50.1 | |
| Digging capacity of tcuket | kN | 179 | |
| Digging capacity of tcuket rod | kN | 125 | |
| Max.traction | kN | 194 | |
| Hydraulic system | Main pump | / | Tow plunger pumps |
| Rated flow of main pump | L/min | 2×256 | |
| Pressure of main safety valve | Mpa | 34.3/37 | |
| Pressure of traveling system | Mpa | 34.3 | |
| Pressure of swing system | Mpa | 28 | |
| Pressure of pilot system | Mpa | 3.9 | |
| Oil volume | Fuel tank capacity | L | 400 |
| Hydraulic tank capacity | L | 240 | |
| Engine oil volum | L | 25 | |
| Apperance size | A Total length | mm | 10160 |
| B Total width | mm | 3190 | |
| C Total heigth | mm | 3000 | |
| D Width of rotary table | mm | 2830 | |
| E Length of track | mm | 4640 | |
| F Total width of chassis | mm | 3190 | |
| G Width of track | mm | 600 | |
| H Wheelbase of track | mm | 3742 | |
| I Track gauge | mm | 2590 | |
| J Counterweight ground clearance | mm | 1100 | |
| K Min.ground clearance | mm | 485(Track teeth not including) | |
| L Min.tail swing radius | mm | 2985 | |
| Working scope | A Max.digging height | mm | 9662 |
| B Max.unloading height | mm | 6810 | |
| C Max.digging depth | mm | 6895 | |
| D Digging depth at the range of 8feets horizontally | mm | 6750 | |
| E Max.vertical digging depth | mm | 5480 | |
| F Max.digging radius | mm | 10240 | |
| G Max.swing height | mm | 3850 | |
| Standard configuration | Boom length | mm | 6000 |
| Length of bucket rod | mm | 2960 | |
| Bucket capacity | m³ | 1.2 | |
| Optional counfiguration | Length of bucket rod | mm | 2500 |
| Bucket capacity | m³ | 1.25Rock bucket | |
| 1.05Earthmovingbucket |
