8 Channel Tablet Capsule Filling Automatic Bottling Electronic Touch Screen Counting Machine Wholesale

Name: 8 Channel Tablet Capsule Filling Automatic Bottling Electronic Touch Screen Counting Machine Wholesale
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

The Marked Prices Of Our Products Are All Range Prices Of The Entire Product Series.

If You Need a Detailed Quotation, Please Send An Inquiry At The Bottom Of The Page.

Attention: 1.All prices and parameters shown above are automatically generated by the system, if you want to know the exact information, please click "Contact Supplier" to send mail to us. 2. Because of the time difference, we suggest that you can choose to send us an inquiry instead of online chat. 3.When sending us an inquiry or message, please tell us your Email or WhatsApp/Wechat/Skype .etc, then our sales manager can contact you quickly.

Product Description

LTEC-Series Automatic Electronic counting machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, Cod liver oil,etc. This machine adopts 16 sets imported counting sensor for counting with 16 Guiding Way and two head. The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by Easy Adjust wheel. The machine comes with Touch screen operation control for convenient running.

Technical Parameters

Model Name	LTEC-8	LTEC-16	LTEC-24	LTEC-32
Application	1. Hard capsules(00-5#)2. Soft Gelatin capsules3. Tablets4. Chewing gums 5. Other solid object under machine range				1. Hard capsules(00-5#) 2. Soft Gelatin capsules 3. Tablets 4. Chewing gums 5. Other solid object under machine range	1. Hard capsules(00-5#) 2. Soft Gelatin capsules 3. Tablets 4. Chewing gums 5. Other solid object under machine range	1. Hard capsules(00-5#) 2. Soft Gelatin capsules 3. Tablets 4. Chewing gums 5. Other solid object under machine range
Hopper Volume	20L	40L	45L	80L
Capacity	10-20bottles/min	40-60bottles/min	40-60bottles/min	40-120bottles/min
Filling Quantity	1-9999pcs/bottle (adjustable)				1-9999pcs/bottle (adjustable)	1-9999pcs/bottle (adjustable)	1-9999pcs/bottle (adjustable)
Bottle Size	Diameter: 30-90mm Height:40-250mm			Diameter: 30-75mm Height:40-250mm		Diameter: 30-90mm Height:40-250mm
Counting Size	Thickness: 3-10mm Diameter: 3-15mm Length: 3-30mm			Thickness: 3-10mm Diameter: 3-15mm Length: 3-25mm		Thickness: 3.5-10mm Diameter: 3.5-15mm Length: 3.5-30mm
Compressed air	0.5Mpa				0.5Mpa
Conveyor Belt Length		2400mm	2400mm	3000mm
Machine Weight	120kg	650kg	750kg	1000kg
Machine Size L × W × H (mm)	6601280780	60024001670	200016001680	220014001680

Product Details

LTEC-Series Automatic Electronic counting machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc.The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table heightby Easy Adjust wheel. The machine comes with Touch screen operation and PLC Control for convenient running.

Mechanism of Push Bottles

Mechanism of Standing Bottle

Conveyor Belt

Blanking

Features

Feeding Mouth and Stop Cylinder:Material: Stainless Steel 304

Sensor Control Board: Adopts Imported Brand Sensor

Accurate, high speed and efficiency

Vibrating Guide Way:

It adopts 3-section electromagnetic Vibrator, frequency is variable and adjustable, to separate counting
objects fast.

1.Compatibility, high accuracy, wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling;

2.Vibratory cutting drugs do not damage;
3.A high degree of intelligence, with no bottle is not the number of self-fault detection alarm and many other control functions;
4.Compact structure, stability and durability, and no regular replacement parts, small footprint, the use of low-cost;
5.To facilitate the replacement of species, can automatically take-off and landing, demolition cleared without any tools,
convenient and quick;
6.Chinese dialogue control panel, can store 10 ~ 20 group of species parameters, adjusted to facilitate the use of special;
7.Fully automatic operation, with the Upper and Lower Union Road, intelligent control of processes, coordination, and no special operation, labor-saving devices.
8.Low prices, especially for small-volume, variety and more manufacturers use.
9.Control chip imported to the United States, photoelectric sensors for Taiwan's imports.

Final Product

Related Products

Company Profile

Our Company

China Ruian City LeadTop Pharmaceutical Machinery Co., LTD (LTPM) is recognized as a major pharmaceutical equipment manufacturer and supplier. Our company is founded in Ruian, China, with a base of 18 years of prior experience in the pharmaceutical industry.
This has allowed us to expand our business in a well-planned manner. We now offer a comprehensive whole production line of quality pharmaceutical machines at competitive prices.

Our Machinery Manufacturing Workshop

Imported CNC Machining Centre makes all parts process accurate. Own R&D team with more than 20 years engineering expereince, can customize the equipment and packaging line to your satisfaction.

Professional Business Team

Warm, professional business team, careful response to your inquiry, timely response rate of more than 93%, higher than the average level of the industry.

Cooperation

Since Its Establishment, The Company Has Had Close Cooperation With More Than 200 Companies All Over The World, And Received Unanimous Praise

Our Certificates

ISO, CE, SGS, BV Certified Company.

Packing & Shipping

All machine delivery with anti rust spray, film wrapping and Sea shipping affordable wooden box.

FAQ

Q: How many different model of Counter you have?
A: Totally we have HY-Series Semi Auto Counter, CountPro-Series Auto Counter, LTEC-Series Automatic Counter.

Q: What is the difference between different Counter?
A: HY-Series are mainly used for TableTop counting, operator needs to manually put bottle under counting nozzle. The advantage of the machine are no change parts, suitable for all kinds object and economic cost. CountPro-Series machine is only used for count capsules, the advantage is economic cost with Fully Automatic Function. LTEC-Series is suitable for all kinds of objects without change parts, Fully Automatic, 100% accuracy, High Speed and multifunction.

Q: How many stage of vibration you have for LTEC-Series Electronic counter?
A: We adopts three stages vibration. The channels are all extra widened for ensure 100% counting accuracy.

Q: How many years of warranty you have for the counter?
A: 5years for LTEC-Series and CountPro-Series. include all mechanical parts and electronic parts. Two years warranty for HY
Series.

Q: Do you have local service all over the world?
A: We have local service in below country: Colombia, America, Canada, Peru, Pakistan, Bangladesh, Vietnam, Philippines, Indonesia,
Ecuador, Dominican Republic, etc.
