DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine

DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine thumbnail-1
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine thumbnail-2
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine thumbnail-3
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine thumbnail-4
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine thumbnail-5
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine photo-1
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine photo-2
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine photo-3
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine photo-4
DPH-260H High Speed Capsule Blister Packing Machine Tablet Blister Packer Blister Packaging Machine photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
2012
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Zhejiang Leadtop Pharmaceutical Machinery Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Our Company
Product Description

Summary

DPH-260H High Speed Roller Type Blister Packing Machine is the new generation product elaborately researched and developed by our company. Its maximum cutting frequency can be 200 times per minute. It combines the advantages of flat type and roller type blister packaging machine, and adopts special feeder for irregular tablet, with high cutting frequency, low energy consumption, accurate action, stable and easy to change mold, high yield, and the stagger blister no horizontal waste edge cutting, highly improves the production efficiency. The machine design is more reasonable, it adopts automatic control technology which integrate frequency control and machine, electricity, light, air, and creative design strictly according to pharmaceutical industry GMP standard.


Technical Parameter for DPH-260H High Speed Blister Packing Machine
Cutting Frequency
70-200 times/min
Production Capacity
12600-36000 blisters/hour
Range Of stroke
20-100 mm
Max. Forming Area
260X250mm
Max. Formed Depth
12mm
Forming power (Upper& Lower)
2KW(×4)
Heat-Sealing power
3KW
Main Motor Power
1.5KW
Total power
380V 50HZ(220V 60HZ)15.5KW
Volume Flux Of Air Pump
≥0.5m3/min
Packing Material Specification
PVC/PVDC/PET: 0.25X260 mm
Alu Foil (PTP) :    0.02X260 mm
Overall machine dimension
4860X1070X1720mm
Overall Packing dimension
5260X1170X2150mm
Weight
3000Kg
Detailed Images
Certifications
Packing & Delivery
Packaging of DPP-250A
Size
4800(L) * 1200(W) * 2000(H)mm
Weight
3400kgs



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated according to customers special request.
Our Service
FAQ

Q1: What information should I let you know if I want to get quotation?

A: -the size of products (Length*Width*Height)

     -the material/ film

     -the required production capacity


Q2: Is there MOQ for our machine?

A: 1 set is acceptable. Of course, if you order more, it will be fine and its price will be more competitive.


Q3: Do you have manual or operation video for us to know more about the machine?

A: Yes, of course. Please email us and ask for it. We will send you soon.


Q4: When can I get the price?

A: We usually quote within 24 hours after getting your inquiry. If you are urgent to get the price, please call us or tell us in your email. We will regard your inquiry priority.


Q5: How does your factory regard quality control?

A: Quality is priority. It's the basement of our company's development. From the beginning of opening company, we especially focus on quality job. Our pharmaceutical equipment have passed the GMP model patents and invention patents issued by State Patent Office of China.
