Application:
The machine is assembled with three parts and can be packed and transported separately. Under control of PLC, the machine can complete separately all procedures including warm-up, blister forming, automatic feeding, heat sealing and synchronous adjustment of Aluminum-Plastic strip, empty-detecting, hard Aluminum forming, second heat sealing, batch number printing, blanking and scrap-collecting, etc.
The machine is suitable for blister packing with Aluminum-Plastic, Aluminum-Aluminum and Aluminum-Plastic-Aluminum.
LTZK Series automatic suppository filling production line has a stable and efficient manufacturing process, filling, freezing, sealing and other production processes to complete the whole process, and the production capacity is 8000-10000 grain/hour.
Main Technical Data:
Production capacity | 8000-12000 pieces/hour |
Dose per unit | 0.5—5ml |
Deviation | <±2% |
Suppository shape | Bullet, torpedo, duck-mouth ect,. |
Adapting base material | Emi-synthesis fatty acid lipo-glycerol, glycerol gelatin, carbon wax |
Volume of storing vessel | 50L |
Air pressure | 0.6Mpa |
Air consumption | 1.5m3 |
Water consumption | 50kg per circle |
voltage | 3PH380V |
Total power | 7.5KW |
contour dimension | 3200mm×3000mm×2300mm |
Total weight | 2000kg |
Feature:
1.PLC checking function:through PLC online checking function to self-checking and alarm for running stoppage,and show the reason of stoppage in order that the operator remedy it in time.
2.Filling part within free static electricity system.
3.Agitation vat speed adjustment system
4.Cooling speed adjustment system
5.Cutting gains speed adjustment system
Notice:end product grains can be set4/5/6/7gains.The machine can product PVC/PE
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the installation and train your workers if you need, but the buyer should bear our technician's round tickets, accomodation, food and subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let us know your scheduel in advance and we will arrange everything for you!
Any other doubts about our machine, please feel easy to contact with us.
