LPG-5 PLC Control Milk Powder Drying Machine
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
-
Portable Water Treatment Plant Water Purification System Water Desalination Equipment
-
LTDG-Series CE Certified High Quality vacuum freeze drying equipment
-
4 Lanes Vertical Liquid Milk Powder Coffee Packaging Machine
-
High quality automatic honey liquid filling machine
-
Stainless Steel Toothpaste Gelatin Shampoo High Shear Homogenizer Vacuum Emulsifying Machine
-
High shear homogenizer vacuum Emulsifying machine make a mayonnaise
Product Description
Product Description
The spray machine for drying is the technology most widely used in the liquid technology shaping and in the drying industry. The drying technology is the most suitable for producing solid powder or particle products from liquid materials, such as: solvent, emulsion, suspension and pumpable paste states, fro this reason, when the particle size and distribution of the final products, residual water contents. Mass density and the particle shape must meet the precise standard, spray drying is one of the most desired technology.
Features
1.Rapid drying speed, which just takes 5-15 seconds.
2.Suitable for thermo-sensitive material and keep the origin state.
3.Simple processing and easy operation, which is suitable for continuous production.
4.The product has a good degree of uniformity, liquidity and dissolubility with high quality and purity.
5.Can adjust the product diameter, density and water content in some degree which is convenient to control and manage.
Technical Parameters
Model | 5 | 25 | 50 | 100 | 150 | 200-2000 | |||||
Inlet temperature | 350°C | ||||||||||
Outlet temperature | 80-90°C | ||||||||||
Max. evaporation(kg/h) | 5 | 25 | 50 | 100 | 150 | 200-2000 | |||||
Centrifugal spraying nozzle transmission mode | compressed air transmission | mechanical transmission | |||||||||
Rotation speed (r.p.m) | 25000 | 22000 | 21500 | 18000 | 18000 | 15000 | |||||
Spray disc diameter | 50mm | 100mm | 120mm | 140mm | 150mm | 180-340mm | |||||
thermal source | electricity | electricity | electricity + steam, fuel, oil, fuelgas | solved by user | |||||||
Max. electric heating power (kw) | 8 | 31.5 | 60 | 81 | 99 | ||||||
Overall dimension | 1.8*0.93*2.2 | 3*2.7*4.26 | 3.7*3.2*5.1 | 4.6*4.2*6 | 5.5*4.5*7 | optional | |||||
Powder recollection (%) | 95 | 95 | 95 | 95 | 95 | 95 | |||||
