Factory Price Centrifugal Spray Dryer Atomized Dryer With CE

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Features:

• The drying speed is high when the material liquid is atomized,the surface area of the material will increase greatly.In the hot-air flow,95%-98% of water can be evaporated at a moment.The time of completing the drying is only several seconds. This is especially suitable for drying the heat sensitive materials.

• Its final products own the good uniformity, flow ability & solubility. And the final products are high in purity and good in quality.

• The producition procedures are simple and the operation and control are easy.The liquid with moisture contents of 40-60%(for special materials,the contents might be up to 90%).can be dried into the powder or particle products once a time. After the drying process, there is no need for smashing and sorting,so as to reduce the operation procedures in the production and to enhance the product purity.The product particle diameters,looseness and water contents can be adjusted through changing the operation condition within a certain range. It is very convenient to carry out control and managment.

Model	LPG-5	LPG-25	LPG-50
Inlet hot air temperature	100-350 ℃ Automatically controlled
Outlet hot air temperature	60-90℃
Max. water evaporation capacity kg/h	5	25	50
Spray nozzle transmission mode	Compressed air transmission	Mechanical transmission
Rotation Speed (r,p.m)	25000	18000	18000
Spraying disc diameter(mm)	50	100	120
Heat supply	EElectricity	Electricity+Steam	Electricity+Steam, fuel oil and gas
Max. electric heating power	9Kw	36Kw	63Kw
Overall dimensions	1.80.932.2m	32.74.26m	3.73.25.1m
Dried powder collecting rate	≥95	≥95	≥95
