Description

DW series many layers belt dryer is used in the material hard to dry and low dry speed. The equipment structure is compact. It covers small area with easy operation, convenient maintain and steady running. The equipment extend and promote the heat wind circle oven which design the dryness process with different heat wind circle as per the dryness characteristics of materials. It is widely used in chemical, metallurgy industry, food, packaging. The dryer has lots of superiorities as high efficiency, saving energy, easy management, larger output, constant product and varied ability.

Technicals

Spec	unit	dw₃-i.2-8		DW 1.6-8	DW₃-1.6-10	DW₃ - 2-8
Unit number			5x3		5x3		5x3
Drying section length	m		30		30		30
Thickness of the material	mm	10-80
Temperature	°C	50-140
Steam pressure	Mpa	0.2-0.8
Steam consumption	kg/h	360-600	420-720	450-840	480-960	480-960	630-1350
Area of heat exchange		816	1020	1056	1320	1344	1680
Drying strength	kgH₂0/h	150-450	220-550	240-600	280-750	280-750	350-900
Power equipment inside	kW	30.8	37.4	42	51	56	68
Power equipment outside	kW	35.3	41.9	46.5	55.5	60.5	72.5
Overall dimensions	m	9.77x2.2x4.5	11.77x2.2x4.5	9.77x2.6x4.5	11.77x2.6x4.7	9.77x3.06x4.9	11.77 x 3.06 x 4.9
Weight	Kg	4800 x 3	5780x3	5400 x 3	6550 x 3	6350x3	7800x3
