Water bath electric heating pasteurization machine and pasteurizer
- 1000 per Month
- T/T Credit Card
- Industry used Vacuum fryer
- High efficiency turnover basket washing machine
- Industry used automatic turnover basket washer
- Automatic turnover basket washing machine equipment washer
- Easy cleaning plastic box washing machine equipment washer
- Automatic Meat Ball Maker Meat ball Former Machine to Make Meat Ball
Product Description
Water bath electric heating pasteurization machine and pasteurizer
Product Desciption
The equipment is made of high quality stainless steel and advanced control instruments. It has beautiful appearance, convenient operation and maintenance. Compared with the current soil method (sterilization tank), it has low labor intensity, less manpower, high degree of self-control, and the temperature can be automatically adjusted within 98 °C. The temperature difference between the upper and lower layers is small, and the product quality is easy to control. This product is in full compliance with quality certification requirements, is hygienic and efficient, and is an ideal equipment for the food processing industry. The equipment adopts double-layer mesh belt setting, which effectively presses the material into the water completely, so that the material is sterilized evenly. The transmission speed of the mesh belt is adjustable. The equipment is equipped with a pneumatic angle seat valve. When the temperature inside the sterilizer is lowered, the steam is automatically replenished. When the temperature inside the sterilizer reaches the set temperature, it is automatically turned off to save energy. The machine has the characteristics of good temperature control, high efficiency and labor saving. The equipment is equipped with a circulation pump to allow the water in the sterilizer to flow to ensure a uniform water temperature. The outer tank body is provided with an insulation layer to reduce heat loss and save energy. A steam outlet is provided at the upper end of the device, and excess exhaust gas is discharged from the exhaust port. The upper cover can be lifted to clean the inside of the body, and the lower end is provided with a sewage outlet for convenient sewage discharge and cleanness. After the material is sterilized, it is transported to the cooler through the mesh belt to cool the entire pasteurization process.
Technical Parameters
Item | Parameter |
Sterilizing time | 10-40min |
Cooling mode | Natural temperature water or chiller cooling water |
Belt width | 800mm |
Sterilizing temperature | 60-95 ℃ |
Capacity | Customized |
Working speed | Stepless speed regulation |
Power | 5.5-120kw |
Voltage | 380V/ Customized |
Machine size | 7000*800*1500mm |
Note | This machine can be customized |
Machine Detail
Packing and Shipping
Company Information
Shandong Jiaxin Industrial Equipment Co., Ltd., located in Zhucheng City, Shandong Province, specializes in the production of food machinery, specializing in Research and Development for pasteurization cooling washing selection drying line for small bag packaged products; bottled tunnel sterilization line; multi-function air bubble washing machine; central kitchen corollary equipment; imitation German horizontal vortex spiral washing machine; clean vegetable processing line; fruit and fish canned products deep processing line; fruit and vegetable crisp chips deep processing line; dehydrated vegetable processing line; mushroom sauce processing line; fruit and vegetable enzyme production line; VD back pressure differential vacuum puff machine; VF vacuum fryer; FD vacuum freeze dryer; brush washing machine; brush washing and peeling machine; various fruits, jujube, red dates, roots, seafood high pressure air bubble vegetable washing line; multi-layer drying line; all kinds of nuts, Chinese herbal medicine, dried fruits and vegetables, mosaics, aquatic products air energy drying machines; air drying lines; frozen foods defrosting, washing and pre-cooking lines; halogen product washing lines; bottled products washing lines; Bags washing line; vibrating sieve; various types of box washing machine and various stainless steel auxiliary equipment. Our products are well sold both in domestic and abroad market. By now we have various kinds of machinery producing equipment, can meet different customers’ requirements.
We have passed ISO9001 and CE certification. We have more than 30 patents and self-managerial import&export authority. We can also design, customize&install project on the spot. To adapt the development and market need, we establish a top-ranking modern production base and sales network covered global market. Our products are exported to The United States, Britain, Australia, Malaysia, Indonesia, Japan, South Korea, North Korea, Bangladesh, Russia, India, Africa, Europe, Southeast Asia and other countries.
