Good Price Wet Type Stirred Drum Granulation Machine for Making Granules
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
- Easy to Operate Wet Type Granulation Machine Granule Making Machine
- Simple Maintenance Good Quality Fertilizer Granules Making Machine
- High Speed Wet Type Powder Mixer Granulator Machine for Sale
- Long Service Life Food Chemical Wet Granulating Machine With Online Support
- Reliable Quality Rapid Powder Mixing Granulator Machine Professional Manufacturer
- Competitive Price Wet Type Mixing Granulating Machine With One Year Warranty
Product Description
Recommend Products
Products Description
The machine is the new type pharmaceutical machinery, designed on the basis of adopting the principle of one-step granulator. It can blend and mix the dry powder rapidly, then the even wet powder and granulator. It meets the requirements of GMP Standard.
It can be widely used in pharmaceutical industry, chemical industry, foodstuff industry, powder metallurgy, cosmetic industry, dying stuff industry, and so on.
The advantages: high-efficient; fast; even; mixing and granulating in the same chamber.
Model | SED-15SZ-H | SED-50SZ-H | SED-80SZ-H | SED-100SZ-H | SED-130SZ-H | SED-200SZ-H | SED-300SZ-H | ||||||
Volume (L) | 50 | 150 | 200 | 250 | 300 | 400 | 600 | ||||||
Capacity (kg/batch) | 15 | 50 | 80 | 100 | 130 | 200 | 300 | ||||||
Blending speed (rpm) | 300/210 | 270/180 | 270/180 | 188/130 | 160/110 | 120/85 | 120/80 | ||||||
Blending power (kw) | 4/5.5 | 9/11 | 11/14 | 11/14 | 11/14 | 15/17 | 22/30 | ||||||
Cutting power (kw) | 1.5/2.2 | 2.4/3 | 3.3/4 | 3.3/4 | 4.5/5.5 | 6.5/8 | 9/11 | ||||||
Cutting speed (rpm) | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | 1440/2900 | ||||||
Working time (min) | 8-15 | 8-15 | 8-15 | 8-15 | 8-15 | 8-15 | 8-15 | ||||||
Particle size (mesh) | 20-80 | 20-80 | 20-80 | 20-80 | 20-80 | 20-80 | 20-80 | ||||||
Overall Size (mm) | 1350*650*750 | 1750*800*1000 | 2050*940*1100 | 2260*940*1100 | 2310*1000*1200 | 2410*1100*1300 | 2610*1230*1500 | ||||||
Weight (kg) | 550 | 698 | 847 | 1020 | 1230 | 1450 | 1800 |
Feature
1. Mix evenly: making sure the coloring particles or pigment are evenly distributed;
2. Strong blending ability: wetting the material quickly with 8-12% thickness starch slurry;
3. Judging the granulating situation by the max electricity consumption;
4. The production granules are relaxed and snow-like with no block, more particle and little powder;
5. The three procedures of the mixing, wetting and granulating run continuously in one barrel avoiding the pollution of the manual contact;
6. It can produce repeated with the right parameters, such as the time and speed of the mixing and granulating, the consumption of the adhesive, the consumption of the electricity, etc.;
7. The producing time is approx. ten minutes with high efficiency and the production particles can be well compressed;
8. The great applicability: it can be used for pipelining with one-step fluidized granulator, as well as the fluidized drier;
9. Saving the adhesive about 20-25% and shorten the drying time;
10. Features: advanced design, reasonable layout, reliable seal, convenient operation, security, reliable, etc
