High Speed Automatic Electric Pharmacy Mini Blister Packing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1995
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
180 Blisters / Min High Capacity Liquid Chocolate Alu Alu Blister Packing MachineNegotiableMOQ: 1 -
Competitive Price Medical Blister Packing Machine Alu Alu for Capsule TabletNegotiableMOQ: 1
-
Rotary Automatic Carton Packing Cartoning Machine for Small BottleNegotiableMOQ: 1
-
20 - 50 Box / Min Rotary Type Automatic Soap Carton Box Packaging MachineNegotiableMOQ: 1
-
New Type Rotary Automatic Bottle Blister Box Cartoning Sealing MachineNegotiableMOQ: 1
Recommend Products
Products Description
SED-250A Blister Packaging machine
TECHNICAL SPECIFICATION:
Model |
SED-250A |
Punch Frequency |
15-55times/min;10-33times/min |
Max.Forming Area&Depth |
250*120(standard depth≤15mm),Max.Depth 30mm(As adjusted) |
Standard Stroke Range |
30-130mm(customized) |
Standard plate size |
80*57(customized) |
Air pressure |
0.4-0.6Mpa |
Compressed Air Required |
Air Compressor≥0.45m3/min |
Total Power Supply |
380/220V 50Hz 8kw |
Main Motor |
1.7kw |
PVC Hard Film |
0.15-0.5*2700(mm) |
PTP Aluminum Film |
0.02-0.035*270(mm) |
Dialysis Paper |
50-100g*270(mm) |
Mould Cooling |
Tap Water or Recycling Water |
Overall Dimension |
2900*750*1600(mm)(L*W*H) |
Weight |
1200kg |
FEATURES:
1、 Pulling length can be adjusted. Mold is fixed by located groove so that it's easy to change mold. The machine heats the PVC through heated board and forms by compressed air frothing.
2、Speed is controlled by invert. It Adopts the interface of human-machine and PLC controller. Adopt universal feeder for feeding.
3、With automatic feeder, we can design the mould and feeder according to customer’s requirement.
4、The machine gets the function for Easy Cutting line embossing, batch number embossing and wasted packaging material rewinding.
5、 Step motor is adopted on the machine for precise controlling on pulling length and saving packing material.
6、The heating molds will automatically separate when the machine stops, which contributes to protect the packing material from heated mould.
APPLICATION:
WORK PROCESS:
1.Forming(up and down heating)
2.Heating Sealing (up heating)
3.Embossing
4.Impression
5.Cutter
6.Finished Product Output
