Wide Range of Application Automatic Medical Capsule Tablet Capsule Blister Packing Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1995
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Multi-functional High Performance Butter Candy Blister Packing MachineNegotiableMOQ: 1 -
Pharmacy Aluminum Plastic Aluminum Capsule and Tablet Blister Packing MachineNegotiableMOQ: 1
-
Long Service Life Chocolate Blister Packing Machine for Pharmaceutical Food IndustriesNegotiableMOQ: 1
-
Automatic Electric Honey Capsule Tablet Blister Packing Machine With Online SupportNegotiableMOQ: 1
-
Low Maintenance Cost High Quality Automatic Medical Blister Packing MachineNegotiableMOQ: 1
Recommend Products
Products Description
APPLICATION
This model is based on the aluminum-plastic blister packaging machine, adding a tropical aluminum forming and sealing station, which makes the product packaging more sealing, moisture-proof and light-proof, and improves the product grade. It is suitable for product packaging in pharmaceutical, food, medical equipment, health care products and other industries. This model adopts the design concept of partitioned clean and humanized, which has the advantages of avoiding pollution, simple operation, convenient maintenance, The features of comprehensive operation monitoring methods can significantly improve work efficiency and reduce labor intensity of workers, and fully solve the disadvantages of inconvenient cleaning and maintenance of traditional models and troublesome mold replacement.
TECHNICAL PARAMETER
Model: |
SED-ZP270TP-B |
||
Punching frequency |
10-35 times/min |
||
Maximum forming area |
120*260mm |
||
Maximum forming depth |
13mm |
||
Traction stroke |
20-120mm |
||
Section reference specifications |
80*57、95*65、103*43 |
||
Packaging material |
Cold formed aluminum foil |
0.15-0.5 × 270mm |
|
Tropical foil max diameter： |
Standard PVC hard film |
0.02-0.035×270 mm |
|
Waste collection max diameter： |
Standard PTP aluminum foil |
0.09-0.15×270 mm |
|
Cold forming(ALU ALU)forming stretch area and depth： |
diameter of the reel |
70-76mm |
|
Air pump capacity |
>0.2m3/min (own) pressure:0.6-0.8 Mpa |
||
Servo motor control stepless adjustable stroke： |
10mm～120mm |
||
Mold cooling |
tap water or recycle water 60L/h |
||
Total motor power |
10KW |
||
Main motor |
2.2KW |
||
Outline size |
5360*850*1750mm |
||
Weight |
4000kg |
||
Feature
The mold structure is openable, which solves the problem of loading and unloading ultra-wide molds quickly. It replaces the traditional column so that avoid oil pollution.
The aluminum ruler shows the position mold base.
The digital position indicator shows how much the of the adjustment has moved.
The cam drive of each station still adopts a one-axis rotation structure to
ensure the synchronization of each station.
Optional visual inspection system of industry-leading brands
Various special feeders (optional).
mesa horizontal brush dust suction device (optional).
Heat sealing with large cylinders solves pressure and buffer problems (standard configuration).
Air cooling is adopted after heat sealing
(standard configuration).
Both the molding material and the sealing material are equipped with monitoring devices
(standard configuration), which will alarm when they are almost used up.
Standard waste collection mechanism.
Can reserve connection interface (optional)
Both forming and sealing bearing shafts adopt inflatable shafts with scales (standard), which can be replaced quickly and easily.
Add a manipulator (optional) to connect with other equipment.
