Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1996
Annual Export Value:
US$10 Million - US$50 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Stainless Steel Tank



Structure:



1. Single layer structure, dual-layer with Jacket or Insulation. Three layer with double jacket.



2. High quality stainless steel 304 or 316L available.



3. Humanized structure design & easy to operate;



4. Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of sanitation;



5. PU Foam Insulation are available to keep temperature.







Configuration:



1. Quick open manhole



2. 360 degree rotation CIP spraying ball;



3. Sanitary breathing cover



4. Adjustable triangular legs



5. Dismountable materials input pipe assembly



6. Mixer: Paddle; Frame; Impeller, Be Vertical or Horizontal to choose;



(Top, bottom side & bottom, etc. places to set the mixer)



7. PU foam Insulation



8. Thermometer , Liquid level meter & ladder (According to customer requirements)



9. Other accessories can make according to customer's special requirements.



molasses mixers





Technical Parameters

Volume

 Height of the whole tank (mm)

Height of the Tank Body (mm)

The Diameter of the Tan Body (mm)

Height of the Discharge Hole (mm)

500L

1725

800

Φ850

350

1000L

1950

900

Φ1100

350

2000L

2500

1300

Φ1300

400

3000L

2800

1500

Φ1500

400

5000L

3100

1650

Φ1800

400

6000L

3350

1800

Φ1900

450

8000L

3600

1950

Φ2100

450

10000L

3800

2000

Φ2300

500

20000L

5350

3400

Φ2600

500



molasses mixersmolasses mixers
