B Series universal grinder/grinding machine
Main Usage:
This machine is applied for materials crushing in such trades as pharmaceutical ,chemical and foodstuff etc .
Features:
Universal Grinder
1.Certificate:GB/T19001-2016 idt ISO9001:2015
2.Simple structure ,high output,easy cleaning.
3.The best grinding fineness.
Working Principle:
By means of relative motion between movable and fixd fluted discs,material is crushed through impact and friction
of the teeth and impact among the materials .Designde according to GMP standard and wholly made of stainless steel
model 30B,moble 40B and model60Bcrushing chamber is equipped with water cooling jacket,with simple structure,
high output and easy cleaning,this machine is the most ideal crushing equipment at present.
Technical parameters:
Model |
20B |
30B |
40B |
60B |
Productive capacity(kg/h) |
60-150 |
100-300 |
160-800 |
500-1500 |
Main shaft speed (r/min) |
4500 |
3800 |
3400 |
2800 |
Inlet particle size(mm) |
6 |
10 |
12 |
15 |
Degree of fineness of finished product(mesh) |
60-120 |
60-120 |
60-120 |
60-120 |
Motor power(kw) |
4 |
5.5 |
11 |
15 |
Weight(kg) |
250 |
320 |
550 |
680 |
Overall dimension(L×W×H)(mm) |
550×600×1250 |
600×700×1450 |
800×900×1550 |
1000×900×1680 |
