0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector

0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector thumbnail-1
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector thumbnail-2
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector thumbnail-3
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector thumbnail-4
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector thumbnail-5
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector photo-1
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector photo-2
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector photo-3
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector photo-4
0.25mm 0.9mm Fiber Optic 2x2 Passive Mechanical Optical Switch With SC FC LC ST Connector photo-5
US$ 15 - 16 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
FY-optical-switch
Place of Origin:
China
Model Number:
FY-switch
Contact Supplier Request Quote Chat Now
Flyin Optronics Co.,Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
3 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name FY-optical-switch
Place of Origin China
Model Number FY-switch
Overview
Quick Details

  • Model Number:

  • 2x2 Mechanical Optical Switch

  • Type:

  • FTTx Solutions

  • Place of Origin:

  • Zhejiang, China

  • Brand Name:

  • FY-optical-switch

  • Use:

  • FTTH

  • Application:

  • MAN; OADM; System Monitoring

  • Product Name:

  • 2x2 Optical Switch

  • Operation Wavelength (nm):

  • 850/1310/1550/1650

  • Return loss (dB):

  • MM≥30 SM≥50

  • Cross Talk (dB):

  • MM≥35 SM≥55

  • PDL (dB):

  • ≤0.05

  • WDL (dB):

  • ≤0.25

  • TDL (dB):

  • ≤0.25

  • Power Supply(V):

  • 3.0 or 5.0

  • Switch time(ms):

  • ≤8

  • Transmission Power(mW):

  • 500
Supply Ability

  • Supply Ability

  • 50000 Piece/Pieces per Month

Packaging & Delivery

  • Port

    • Shanghai/Ningbo

  • Lead Time:

  • Quantity(Pieces) 1 - 200 >200
    Est. Time(days) 7 To be negotiated
Product Description
2x2 Mechanical Passive Optical Switch,Operation Wavelength:850nm OR 1310nm OR 1550nm OR 1650nm OR 1310/1550nm OR Specify,Insertion Loss:Typ:0.8(Max:1.2) OR Type:0.8(Max:1.0),Return loss:MM≥30 OR SM≥50,Voltage Type:3V OR 5V,Control Model: Latching OR Non Latching,Fiber Type:SM 9/125 OR MM 50/125 OR 62.5/125 OR Specify, Fiber Diameter:250μm OR 900μm,Fiber Length:1m OR 1.5m OR Specify,Connector:None OR SC/APC OR SC/UPC OR FC/APC OR FC/UPC OR LC/APC OR LC/UPC OR ST OR Specify.
Feature
⊙Low crosstalk
⊙Low insertion loss
⊙Wide wavelength range
⊙Latching and non-latching
⊙Epoxy free on optical path
⊙High stability and reliability
Application
⊙ MAN
⊙OADM
⊙R&D laboratory
⊙System monitoring
Parameter
Parameter
2x2 Mechanical Optical Switch
Operation Wavelength (nm)
850
1310/1550/1650
Wavelength Range(nm)
850±40
1260~1650
Insertion Loss (dB)
Typ:0.8 Max:1.2
Typ:0.8 Max:1.0
Return Loss (dB)
MM≥30 SM≥50
Crosstalk (dB)
MM≥35 SM≥55
PDL (dB)
≤0.05
WDL (dB)
≤0.25
TDL (dB)
≤0.25
Repeatability (dB)
≤±0.02
Power Supply (V)
3.0 or 5.0
Lifetime (Times)
≥10^7
Switch Time(ms)
≤8
Transmission Power(mW)
500
Operating Temperature(℃）
-20~+70
Storage Temperature(℃）
-40~+85
Weight（g）
16
Dimension（mm）
L27.0 × W12.0 × H8.2
Specifications
Voltage
Current
Resistance
5V Latching
4.5~5.5
36~44mA
125Ω
5V Non-Latching
4,5~5.5
26~32mA
175Ω
3V Latching
2.7~3.3
54~66mA
50Ω
3V Non-Latching
2.7~3.3
39~47mA
70Ω
Order Information
Mode
Wavelength
Voltage Type
Control Model
Fiber Type
Fiber Diameter
Fiber Length
Connector
A=SM
A=850nm
A=3V
A=Latching
A=SM 9/125
A=250μm
A=1m
A=None
B=MM
B=1310nm
B=5V
B=Non-Latching
B=MM 50/125
B=900μm
B=1.5m
B=FC/APC
/
C=1550nm
/
/
C=MM 62.5/125
/
C=Specify
C=FC/UPC

D=1650nm

D=Specify

D=SC/APC

E=1310/1550nm




E=SC/UPC

S=Specify




F=LC/APC







G=LC/UPC







H=ST







I=Specify


Product Tags: fiber Optical Switch , 2x2 Switch , mems Optical Switch
