Home > Manufacturing & Processing Machinery > Pharmaceutical Equipment & Machinery > Pharmaceutical Injection Equipment > 1400 Degree Laboratory Digital Oven Ceramic Furnace Electric Chamber for Metal Heating and Hardening
1400 Degree Laboratory Digital Oven Ceramic Furnace Electric Chamber for Metal Heating and Hardening
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2004
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Laboratory Muffle Furnace 1200 Degree Small Size Electric Kiln Heat Treatment Oven for Melting and SinteringNegotiableMOQ: 1 -
Laboratory Vacuum Atmosphere Tube Furnace 1200 1400 1700 Degree Chemical Vapor Deposition CVD Diamond MachineNegotiableMOQ: 1
-
1200 Degree Lab Atmosphere Furnace Electric Heat Treatment Denture Zirconia Sintering Oven Dental Porcelain FurnaceNegotiableMOQ: 1
-
1400 Degree Laboratory Electric Pottery Kiln Nitrogen Argon Atmosphere Furnace Vacuum Heat Treatment FurnaceNegotiableMOQ: 1
-
Muffle Furnace 1700 Degree Mini Laboratory Electric Kiln Heating Equipments Ceramic Oven For PotteryNegotiableMOQ: 1
Products Description
Application | Tefic TX2 series muffle furnace has the advantages of small size, light weight, balanced temperature field, rapid temperature rate, and energy saving. It is an ideal equipment for high temperature sintering, composition analysis and quality testing in labs of universities, research institutes, industrial and mining enterprises. | ||||||
Working /highest temperature | 1100℃/1200℃ | 1300℃/1400℃ | 1600℃/1700℃ | ||||
Temperature control accuracy | ±1℃ | ±1℃ | ±1℃ | ||||
Thermocouple and measuring range | K type（0-1200℃） | S type（0-1600℃） | B type（0-1820℃） | ||||
Heating element | Resistance wire | Silicon carbon rod | Silicon molybdenum rod | ||||
Furnace Chamber | 3 sides heating | 2 sides heating | 2 sides heating | ||||
Heating rate | The maximum heating rate is 30 ℃ / min, and 20 ℃ / min is recommended. | ||||||
Voltage | 220V 50HZ/110V 60HZ/380V 50HZ | ||||||
Appearance design | The electric furnace adopts humanized design, which is beautiful and easy to operate. The outer layer of paint is baked by spraying plastic at high temperature. It has high temperature resistance, oxidation resistance and acid-base resistance. Color selection for aging resistant hue, not because of the use of a long time to produce appearance color fading. | ||||||
Body design | The double-layer forced air cooling structure is adopted in the electric furnace shell, which makes the external temperature of the furnace shell close to the room temperature when the furnace is working at the highest temperature, thus avoiding the occurrence of accidental injury. | ||||||
Temperature control | Adopt international advanced temperature control instrument: with 30-50 segment programmable PID self-tuning, automatic heating, automatic cooling, no need to be on duty. RS-485 communication interface can also be selected (connect with ordinary computer to start, stop, pause temperature rise, set temperature rise curve, store temperature rise curve, record historical curve, etc.) | ||||||
Temperature control safety | The furnace adopts integrated circuit, module control, double circuit protection (partial temperature protection, ultra-high temperature protection, broken couple protection, over current protection, overpressure protection and other protection functions) to make the furnace work stable, reliable and safe. | ||||||
Chamber material | The light alumina ceramic fiber is used internationally, which has excellent heat preservation effect, light weight, high temperature resistance, quick cooling and heat resistance, no crack, no crystallization, no slag falling, no worry about pollution of the products. The energy saving effect is 60% to 80% of the old electric furnace. | ||||||
Chamber design | The furnace adopts the step type assembling structure and integrates the mechanical laws, which effectively guarantees the uniform stress of the furnace in the heating process, ensures that the heat energy is not easy to be lost, and extends the service life of the furnace. | ||||||
Warranty | The electric furnace is free of charge for 12 months (except for heating body), and the heating body and cooling fan shall be replaced free of charge in case of natural damage within 3 months. | ||||||
Accessories | Standard accessories: crucible forceps 1, special high temperature gloves 1 pair. One copy of the instructions. Optional accessories: touch screen control, configuration air inlet exhaust chimney, paperless recorder, remote communication control system. | ||||||
Chamber sizes(mm) | 100*100*100 150*100*100 200*150*150 300*200*200 400*300*300 Note: more chamber sizes and can be customized) | ||||||
We offer a series of standardized muffle furnace to satisfy the requirements of most customers. We can also provide solutions tailored to your unique requirements. We are ready to serve you upon request.
