Heat Seal Tester One & Five Heating Points Flexible Package Test
Products Details
Application:
Applies to best parameters determination of heat sealability of various kinds of film. Heat sealability of film depends on temperature, pressure and heat time and the HSL Heat Seal Tester is widely used in food and pharmaceutical packaging industries. Heating Seal Test Instruments Heat Seal Parameters.
Heat Seal Tester One & Five Heating Points Flexible Package Test
Features:
1: Our own unique technology
2: Embedded system control
3: Touch screen operation, easy to operate
4: TFT LCD display, UI flattening design
5: Dual heat jaws, temperature controlled independently
6: Micro-printer prints mini-report
7: Pressure easy to adjust, heat temperature and time touch screen input.
8: Emergency stop button, safety design to prevent burns
9: Over temperature protection, over pressure protection
10: Silence working
11: DB9 RS232 communication port.
12: DSM system is optional(Laboratory Management Information System), easy to manage and share test data.
Heat Seal Tester One & Five Heating Points Flexible Package Test
Technical Indexes:
| Heat temperature | Room temperature+6 ~ 300℃ |
| Accuracy | ±0.2 ℃ |
| Dell time | 0.1~ 999.9s |
| Pressure | 0.05 MPa~1.1MPa |
| Heat jaw surface | 265mm × 12 mm (customized) |
| Heat jaws | 2, controlled independently |
| Gas source pressure | 0.05MPa ~ 1.1MPa (self-provide) |
| Gas source interface | Ф6mm |
| Outer dimension | 536 mm (L)×335 mm (W)×413 mm (H) |
| Work noise | 0db |
| Power supply | AC 220V 50Hz |
| Net weight | 33kg |
