Help CenterSeam Welder SBFN-35 SBFN-55 SBFN-75 SBFN-100
Related Products
For customers with no special requirements regarding the welding appearance, we recommend using this seam welder. This seam welding machine produces a current by the collision of the anode and cathode for welding sheet metal. The welding arc is specifically modified for special characteristics found in galvanized sheet metal to create a firmer stitch on the galvanized sheet metal. It carries out both pulse and continuous weld, with an adjustable welding speed on the control panel.
Parameter:
Item Type |
SBFN-35 |
SBFN-55 |
SBFN-75 |
SBFN-100 |
Thickness |
0.4-1.0 mm |
0.4-1.2 mm |
0.4-1.5mm |
0.4-2.0mm |
Max Input Capacity |
45KVA |
55KVA |
75KVA |
110KVA |
Max,Short Circuit Current |
6200A |
11000A |
16000A |
26000A |
Max,Pressure Of Electrode |
400KGF |
600KGF |
1000KGF |
1000KGF |
The Flow Of Cooling Water |
6L/min |
6L/min |
8L/min |
8L/min |
Arm Lenghth |
600mm |
600mm |
600mm |
600mm |
Electrode Journey |
80mm |
80mm |
80mm |
80mm |
Speed Of Welding |
0.5-3m/min |
0.5-3m/min |
0.5-3m/min |
0.5-3m/min |
weight |
328Kg |
378Kg |
428Kg |
478Kg |
Dimension |
1800×610×1930mm |
1800×610×1930mm |
1800×610×1930mm |
1800×610×1930mm |
