Energy Saving Silencing Check Valve

Main performance specification
Type	Nominal pressure	Shell test pressure	Seal test pressure	Applicable medium	Working temperature
H41X-10	1.0MPa	1.5MPa	1.1MPa	Water and weak corrosive fluid	W80P
H41X-16	1.6MPa	2.4MPa	1.76MPa	Water and weak corrosive fluid	W80P
Major parts material
Type	valve body	Sealing ring	spring
H41X-10	Cast iron or stainless steel	Nitrile rubber (NBR)	Stainless steel wire ICr18Ni9Ti
H41X-16	Cast iron or stainless steel	Nitrile rubber (NBR)	Stainless steel wire ICr18Ni9Ti

PN	DN(mm)	Size(mm)
PN	DN(mm)	L	D	K	b	Z-Φd
1.0MPa	40	112	145	110	18	4-Φ18
	50	120	160	125	20	4-Φ18
	65	130	180	145	20	4-Φ18
	80	150	195	160	22	8-Φ18
	100	165	215	180	24	8-Φ18
	125	190	245	210	26	8-Φ18
	150	210	280	240	26	8-Φ22
	200	255	335	295	28	8-Φ22
	250	310	390	350	28	12-Φ22
	300	320	440	400	28	12-Φ22
	350	380	500	460	30	16-Φ22
	400	405	565	515	32	16-Φ26
	450	430	615	565	32	20-Φ26
	500	450	670	620	34	20-Φ26
	600	510	780	725	36	20-Φ30

PN	DN(mm)	Size(mm)
PN	DN(mm)	L	D	K	b	Z-Φd
1.6MPa	40	112	145	110	18	4-Φ18
	50	120	160	125	20	4-Φ18
	65	130	180	145	20	4-Φ18
	80	150	195	160	22	8-Φ18
	100	165	215	180	24	8-Φ18
	125	190	245	210	26	8-Φ18
	150	210	280	240	26	8-Φ22
	200	255	335	295	30	8-Φ22
	250	310	405	355	32	12-Φ22
	300	320	460	410	32	12-Φ22
	350	380	520	470	36	16-Φ22
	400	405	580	525	38	16-Φ26
	450	430	640	585	40	20-Φ26
	500	450	715	650	42	20-Φ26
	600	510	840	770	48	20-Φ30
