Allen Bradley 1756-IF16IH HART Analog Input Module With Good Price In Stock

Allen Bradley 1756-IF16IH HART Analog Input Module With Good Price In Stock

The 1756-IF16IH module is an isolated, 16-channel, current-only input module capable of HART communication on all channels. Each channel is individually configurable.

The 1756-IF16IH module has the following features:

• 16 isolated, individually configurable input channels with a separate HART modem on each channel

• Channel-to-channel, channel-to-backplane, and channel-to-frame ground galvanic isolation at a continuous level of 250V AC rms

• Two input ranges: 0…20 mA and 4…20 mA

• Compatible tag layouts with the non-isolated 1756-IF16H module for use of the 1756-IF16IH module in existing systems:

– 1756-IF16H compatible configuration Instance

– 1756-IF16H compatible input data tag layouts for Analog Only, Analog and HART PV, and Analog and HART PV by Channel Grouped

• Supports full simultaneous HART 1200 baud bandwidth to all channels

• Channel ADC filter (one setting per module)

• Digital filtering (configurable per channel)

• Real-time sampling

• Auto-scanning of HART variables (PV, SV, TV, FV)

• HART pass-through interface

• User scaling of input data

• Time stamping

HART Compatibility

The 1756-IF16IH functions as a HART master. It communicates with HART devices that have a HART revision of 5, 6, or 7. Each channel has its own HART modem and functions as a HART primary master. The 1756-IF16IH module supports one HART device per channel. The 1756-IF16IH module does not support burst mode, phase shift keying (PSK), or multi-drop network configuration. The module detects and turns off a bursting device at initial connection with the device.
