Allen-Bradley POINT I/O 4 Point Analog Output Module 1734-OE4C With Good Price In Stock
- 1000 Piece / Pieces per Month
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
Product Description
Allen-Bradley POINT I/O 4 Point Analog Output Module 1734-OE4C With Good Price In Stock
The Allen-Bradley 1734-OE4C is a POINT I/O Analog Output Module. It has Four (4) single-ended, non-isolated, Current output module with Current range of 4 to 20 mA or 0 to 20 mA. It has an integrated Digital to Analog converter with conversion resolution of 16 Bits and absolute accuracy of 0.4% (0.1% if calibrated).
Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1734-OE4C |
Series | POINT I/O |
Module Type | Analog Output Module |
Outputs | 4 Single Ended |
Data Format | Signed Integer |
External DC Supply Current | 220 mA |
Output Signal Range | 4 to 20 mA, 0 to 20 mA |
Output Resolution | 16 bits across 0 to 21 mA |
Conversion Type | Digital-Analog |
Conversion Rate | 20 microseconds |
Resolution | 14 bits |
Weight | 1.27 ounces (36 grams) |
Dimensions (H x W x L) | 2.21 x 0.47 x 2.97 inches |
DC Voltage | 10 and 28.8 Volts DC |
Power Dissipation | 750 Ohms at 1.86 Watts |
UPC | 10612598205292 |
UPC | 10612598345431 |
The module has a compact form and designed for DIN rail mounting. This module may be used with POINT IO communication adapter such as ProfiBus, ControlNet and Ethernet adapters. The module has several adjustable parameters such as input filters and signal type which is configurable with the use of RSLogix 5000 or Studio 5000 Logix Designer software. The 1734-OE4C memory register is accessible by connecting online to the Programmable Logic Controller’s (PLC) processor. The module’s register is composed of Channel Data and Channel Status. The module’s register size is 4 Bytes.
The 1734-OE4C has Module Status and Network Status indicator light as well as Status indicators for every channel. These indicators are installed on the module’s front panel to indicate the module status, network and channel activity.
Compatible wiring assembly for this analog output module are 1734-TB or 1734-TBS. The 1734-OE8C has a dimension of 56.0 x 12.0 x 75.5 mm (2.21 x 0.47 x 2.97 in.) and weighs 36 g (1.235 oz). Recommended signal wire sizes for this module measures 0.25 to 2.5 mm. sq. or 22 to 14 AWG solid or stranded copper wire rated at 100 ° C (212 ° F), or greater. Recommended maximum insulation size is 1.2 mm (3/64 in.).
The Allen-Bradley 1734-OE4C POINT I/O Analog Output Module comes with Four (4) single-ended, non-isolated, current outputs. It has an output signal range of 0 to 20 mA and a default range of 4 to 20 mA with integral digital to analog converter circuit. It has an output conversion rate of up to 1 ms with an output current accuracy of 0.1% full scale at 77 degrees Fahrenheit (25 degrees Celsius). The module’s current output is 40 ms with output resolution of 16 bits over 0 to 21 mA, 2.5 microA/cnt. The converted data format is in the form of Signed Integer.
The Allen-Bradley 1734-OE4C’s point-bus current reaches up to 75mA at 5 Volts DC. It has a power dissipation of 750 Ohms on each 1.86 Watt output and 0 Ohms on each 2.15 Watt channel. The 1734-OE4C’s maximum thermal dissipation reaches up to 750 Ohms load on each output at 6.34 BTU/hour and a 0 Ohm load on each channel at 7.33 BTU/hour. Compatible terminal base for this module are 1734/TB/TBS/TOPS/TOP and installed with the keyswitch set to position 4. The module’s nominal voltage supply is 24 Volts DC with acceptable range of 10.0 to 28.8 VDC. It has an isolation voltage of 50 Volts continuous with a basic insulation type, tested to withstand 1500 Volts AC for 60 seconds.
The 1734-OE4C’s operating temperature range is -4 to 131 degrees Fahrenheit and its storage temperature range is -40 to 185 degrees Fahrenheit. It has an operating shock of 30 G and a non-operating shock of 50 G. Its relative humidity reaches up to 95% non-condensing with operating vibration of 5 G at 10 to 500 Hertz. This analog output module has an output resolution of 16 bits across 0 to 21 mA.
