2 Channel Bandwidth 50MHz Sampling Rate 200MSa/s DSCope C20P 200MHz USB Digital Oscilloscope
- 1000 per Month
- T/T Credit Card
- 64K 250MHz Bandwidth 1GS/s Sample Rate Range Hantek DSO4254C 4CH Digital Oscilloscope
- Spectrum Analyzer Low Frequency Converter BG7TBL
- APS-1001D 1KVA 0-300V Output AC Power Variac Autotransformer Voltage Regulator
- NEMA23 JMC iHSV57-30-18-36-01-BY 36VDC 180W 3000rpm 0.6Nm 57 Integrated Servo Motor
- 1.0-5.0mm AC100-240V Fuma FA-560 Automatic Screw Feeder Machine Conveyor Screw Arrangement Machine
- FA-580 Automatic Screw Feeder w/ Counting Digital Display Buzzer for 1-5mm Screws
Product Description
DSCope C20P 200MHz USB Digital Oscilloscope 2 Channel Bandwidth 50MHz Sampling Rate 200MSa/s
Description:
DSCope C20P is a USB-based oscilloscope, with 50MHz bandwidth, max 200MSa/s sample rate, 1M real-time and 16M single record length.
It’s so small(103mmx74mmx13mm), and can be packed in a shirt pocket. Combined with big screen and powerful performance computer, DSCope C20P can provide you amazing signal capture and analyzer experience.
Features:
Powerful FPGA Waveform Processing Engine
-High-bandwidth parallel architecture: greater than 60fps processing power
-Real-time transmission of each frame waveform: less than 10ms transmission delay
Optimized Analog Frontend
-50MHz analog bandwidth
+-100V input voltage range
-Ground shield
-Immersion gold technology
Unibody CNC Aluminum Case
-Except an awesome appearance, fully metal case can provide extremely shielding protection, which make DSCope immune to environment noises.
High-performance PC Software
-Waveform without delay
-Smooth operation
-Big adjustable screen for nice interactive experience
-Clearer waveform
Oscilloscope in Pocket
-DSCope has ultra-portable size. You can take it anywhere in your pocket. Best choice for field engineers.
FFT-based Spectrum Analysis
-FFT-based real-time spectrum analysis has controls of FFT length (1k-16k), Sample interval, FFT window (Rectange/Hann/Hamming/Blackman/Flat_top) and Y-axis mode.
Rich Measurement Options
-Auto Measurement: Ferq/Period/Vmax/Vmin/Vrms/Vmean/Vp-p
-Manual Measurement: Ferq/Period/Duty cycle
-Vertical Measurement: Voltage
Long Record Length
-1M sample depth @ real-time mode
-16M sample depth @ single mode
-Large depth will help to keep a high sample rate in long time capture, avoid to loss any details of under-test signals.
Data Acquisition Mode
-Real time wave rendering
-Long duration capture (>24hours @ 1KHz)
-Uninterrupted acquisition
Upgrading
-Free software
-Automatic upgrading for firmware
System Requirements:
- For Windows XP, Vista, Win7, Win8 & Win10
- For Mac OS X 10.9 or above
- For Linux: recent Ubuntu, Fedora, Arch, etc.
- For USB 2.0 Host port
Package Included:
- 1 x DSCope C20P
- 1 x USB Cable
- 2 x P6100 Probes
Detail photo
