High-Efficient HVAC Carrier Industrial Chiller 140kw Low Temperature Air Cooled Chiller
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1991
Annual Export Value:
US$1 Million - US$1.5 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PET Bottle Cutting Machine Soundproof Plastic Crusher For Granulator HDPENegotiableMOQ: 1 -
5 Ton Water Cooled Water Chiller Price For Laser MachineNegotiableMOQ: 1
-
CE Certified Hermetic Compressor R22 Refrigeration Water-Cold Industrial ChillerNegotiableMOQ: 1
-
Industrial CO2 Water-Cooled Chiller Supplier In MachineryNegotiableMOQ: 1
-
Industrial 1 hp 3kw R22 Refrigerant Mini Recirculating Air Cooled Water ChillerNegotiableMOQ: 1
Product Description
Air Cooled Water Chiller
Industrial chillers are widely used in plastics, electronics manufacturing, electroplating, pharmaceutical and chemical, ultrasonic cooling, printing and other industrial productions. It can precisely control the temperature required for modern industrial manufacturing and largely improve efficiency and product quality. It is the best choice for modern industries with simple operation, reasonable design and superior quality and over one hundred different models.
Suitable for various industries
Industrial water chiller is to provide a cooling process in plastic molding, to improve quality of molded products and shorten period of injection molding cycles. Hence maximizes productivity of plastic molding manufacturing.
Product Specifications
Model |
Unit |
XC-LF20A |
XC-LF25A |
XC-LF30A |
|||||
Cooling Capacity |
KW |
71.9 |
81.4 |
108.5 |
|||||
Kcal/h |
61902 |
70021 |
93361 |
||||||
Compressor |
Input Power |
KW |
7.5*2 |
9*2 |
7.5*3 |
||||
Rated Power |
HP |
10*2 |
12.5*2 |
10*3 |
|||||
Power |
3PH-380V/50HZ |
||||||||
Evaporator |
Type |
Shell and Tube |
|||||||
Pie Diameter |
inch |
2.5'' |
2'' |
2.5'' |
|||||
Refrigerant |
Type |
R22 |
|||||||
Quantity |
KG |
11 |
11 |
12 |
|||||
Condenser(air chiller) |
Type |
Finned Copper Tube + Low Noise Outer Rotor Fan |
|||||||
Fan Power |
W |
420*2 |
800*2 |
800*2 |
|||||
Water Tank Capacity |
Liter |
130 |
130 |
150 |
|||||
Pump |
Power |
KW |
2.2 |
4 |
4 |
||||
HP |
3 |
5 |
5 |
||||||
Distance |
m |
16 |
16 |
16 |
|||||
Flow Rate |
L/min |
360 |
700 |
700 |
|||||
Safety Protection |
High and Low Pressure Protection, Overload Protection,Overtemperature Protection, Phase Sequence Protection,etc. |
||||||||
Dimensions(L*W*H) |
mm |
2150*1000*1780 |
2400*1150*1800 |
2600*1150*1900 |
|||||
If you want more sizes, please contact us for details
Product Actual Shooting
Product Details
01 Microcomputer LCD Controller
▪ Simultaneously displays the cold water outlet and the set temperature;
▪ Easy to operate with accuracy of controlling water temperature within 3℃ to 50℃.
02 Famous Band Compressors
Using famous brand Copeland compressor, with lower noise and less vibration, efficient and energy saving.
Shell and tube evaporator adopts high-precision internal threaded copper tube design with larger heat exchanging area for higher efficiency and maximizing system performance.
With high efficient fin type condenser and silent refrigeration fan, no need to equip cooling water, easy to install.
Advanced stainless steel Oakland water pump, with large working range, low noise, reliable performance and no leakage and maintenance-free.
Instead of capillary copper tube, it is resistant to high temperature and high pressure, and will not cause refrigerant leakage due to excessive pressure.
Protection System
Current overload protection, high and low pressure protection system and electronic time delay, and an abnormal visual displaysystem.
Application Range
The chiller is used in the plastic processing machinery mold cooling, electroplating industry,machinery industry, building industry, vacuum coating and food industry,etc.
