High quality price per meter of fiber optic cable 4 core figure 8 fiber optic cable
- 1000 per Month
- T/T Credit Card
You May Like
-
GYFTC8Y Non-metallic Self-supporting Outdoor Figure 8 Fiber Optic Cable China Shenzhen Shanghai Manufacturing Supplier
-
Figure 8 sm self supported 6/12/24 core fiber optic cable bow type high speed cabling
-
Figure 8 sm self supported cable 6/12/24 core fiber optic cable manufacturer in China
-
China supplier cable fiber drop wire 48 core single mode copper drop wire fiber optic cable price per meter
-
12 24 48 core fiber optic cable 204 core figure 8 FO Cable Figure 8 Aerial Self-supporting Fibre Optic Cable gytc8y
-
Metallic Messenger 12 24 48 core FO Cable Figure 8 Aerial Self-supporting Fibre Optic Cable
Product Description
Figure.8 Cable with steel tape or aluminum tape(GYXTC8S/GYXTC8A)
1) The type of this fiber with single-mode G652 G655 G657 or multimode 50/125, 62.5/125. etc, with a loose tube which is made of high modulus plastic
2) 2~12 fibers, jelly filled, fiber contained central loose tube, water blocking jelly,copolymer coated PSP or APL, PE outer sheath, fig 8 type, one steel wire suspension line
3) This cable is light, flexible, easy for the laying and it is one of products for FTTH solution.
APPLICATION
1) Adopted to areial self-supporting installation
2) Long-distance communication, local trunk line, CATV & computer networks system.
CABLE INFORMATION
| Cable type | Cable diameter mm |
Cable weight Kg/km |
Tensilse Strength Long/Short term N |
Crush Resistance Long/Short term N |
| GYXTC8S-2-8 | 8.1×16.9 | 117 | ≥2000/≥6000 | ≥300/≥1000 |
| GYXTC8S -10-12 | 8.1×16.9 | 121 | ≥2000/≥6000 | ≥300/≥1000 |
| Optical Characteristics: | ||||
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
| A1b:62.5/125 | ||||
| Singlemode | G.652(A,B,C) | B1.1:Conventional fiber | ||
| G.652D | B2: Zero dispersion shifted | |||
| G.655 | B1.2 :Cut-off wavelength shifted | |||
| G.657(A1,A2 ,B3) | B4: Main technical data for positive | |||
| dispersion shifted single-mode fiber | ||||
Note:
3. Specially designed Cable structure is available on request.
Photo show:
1. Shipping: By sea or air due to heavy weight. Samples will be send by DHL, Fedex. etc
2. Payment: We accept T/T, L/C and Western Union, just choose what you like
3. Delivery time: Generally 3~7 working days upon receipt deposit. According to the quantity.
4. MOQ: Generally our MOQ is 1000meters. samples below 1meter can be provided freely
Quote Request Information
1. Fiber Count: 2 to 12 Fibers
2. Fiber type: Single mode: G652D, G655,G657. Multimode: 50/125,62.5/125. OM3
3. Order Quantity
FAQ
1.Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.
2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.
5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.
