Help CenterGL LSZH China Factory FTTH Drop Cable Single Mode 2 Core Drop Wire Telephone Cable
Related Products
-
GL Ftth Fiber G657a G652d 1 2 4 Core Self Supporting Lszh Jacket Sheath Fiber Optical 2 Core Drop Wire Telephone CableNegotiableMOQ: 1 -
Factory Supply Ftth Fiber G652d 1 2 4 Core Self Supporting Lszh Jacket Sheath Fiber Optical Drop Wire CableNegotiableMOQ: 1
-
LSZH China Factory High Quality G652D Cable 12 Cores 48 Cores Single Mode FTTH Drop CableNegotiableMOQ: 1
-
High Factory G675A 1 2 4 6 8 Core FTTH Drop Cable Indoor Fiber Optic Cable 2 Core Ftth With Messenger Wire in TelecommunicationNegotiableMOQ: 1
-
GL FTTH Fiber to the Home Single Mode Fiber Optical Drop Cable 1 2 4 Cores Fibra Optica LSZH JacketNegotiableMOQ: 1
|
Type |
Fiber Count |
Cable Diameter |
Cable Weight kg/km |
Supporting Wire Spec |
Connection Diameter |
Tensile Strength Term N |
Crush Resistance |
|
Drop cable |
2~12 |
24 |
0.9 mm |
Height×Width |
|
No. |
Items |
Unit |
Specification |
|
|
G.652D |
||||
|
1 |
Mode Field Diameter |
1310nm |
μm |
9.2±0.4 |
|
1550nm |
μm |
10.4±0.5 |
||
|
2 |
Cladding Diameter |
μm |
124.8±0.7 |
|
|
3 |
Cladding Non-Circularity |
% |
≤0.7 |
|
|
4 |
Core-Cladding Concentricity Error |
μm |
≤0.5 |
|
|
5 |
Coating Diameter |
μm |
245±5 |
|
|
6 |
Coating Non-Circularity |
% |
≤6.0 |
|
|
7 |
Cladding-Coating Concentricity Error |
μm |
≤12.0 |
|
|
8 |
Cable Cutoff Wavelength |
nm |
λcc≤1260 |
|
|
9 |
Attenuation(max.) |
1310nm |
dB/km |
≤0.36 |
|
1550nm |
dB/km |
≤0.22 |
||
MORE PRODUCT
COMPANY IMFORMATION
Hunan Guanglian Photoelectricity Technologies Co., Ltd(GL technology) is a professional manufacturer of fiber optic cable. GL technology offers its customers a complete range of indoor & outdoor cables,including FTTH drop cables/ aerial fiber optic cable / duct fiber optic cable /directly buried fiber optical cable, ADSS,OPGW and OPPC for power system transmission in China.
Over 2000.00km of fiber optic cables installed, with sold over the world more than 30 countries. GL technology have been used in various fields over the world. In GL technology, We supply a full system and providing fiber optic cable system solutions and technical assistance for you. Customers who choose the GL technology can be sure that their decision will lead to a successful experience.
Certification
FAQ
1.Are you the real manufacturer?
Us. We are the real manufacturer with 17 year’s history.
2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.
5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 10% in advance and 90% before shipment.
