Home > Products > OPGW Cable > GL Fibre Optic Cable Opgw de Sevicio Fibra Opotica 24/28/36/48/96 Core Opgw
GL Fibre Optic Cable Opgw de Sevicio Fibra Opotica 24/28/36/48/96 Core Opgw
- T/T Credit Card
You May Like
-
OPGW Optical Fiber Cable Youxin Ningbo France Optic Fiber Drop Cable
-
G652D OPGW Typical Designs of Central Stainless Steel Loose Tube
-
GL 2-144 Cores G652.D FTTH Fiber Drop Cable Indoor GJYFXTBY Cabling FTTX FTTA Flat Drop Fiber Optic Price List
-
Verified Factory Supplies Optic Fiber CABLE OPGW 6 8 12 24 48 96 144 196 Core Single Mode Fiber Optic Cable Price Per Meter
-
GL High Quality Low Price Single Mode Fiber Opgw 24 /36/48 Core Overhead Fiber OPtic Cable Price
-
GL Factory Supplies Optic Fiber Cable OPGW 6 8 12 24 48 96 144 196 Core Single Mode Fiber Optic Cable Price Per Meter
Product Description
GL fibre optic cable opgw de sevicio fibra opotica 96 hiloscable drop 2core sm lszh itu-t g657 a1optical fibercable 12core
Description:
The central stainless steel tube is surrounded by single or double layers of aluminum clad steel wires(ACS) or mix ACS wires and aluminum alloy wires. are the most widely used cables ,their design is fully adapted to the most common electric line needs.
Characteristic:
1. High quality standards for designing, testing and producing with grade A materials available to ensure long-term reliability .
2. Engineering support supervising and providing its own line of accessories hardware .
3.Seal stainless steel tube superior protection to the fiber optical to moisture and extreme environmental conditions such as lightening
4. To construct OPGW must cut power, resulting in greater loss, thus OPGW must be used in constructing high pressure line over 110kv;
5. Apply to the transformation of old lines.
Standards:
|
ITU-TG.652 |
Characteristics of a single mode optical fiber |
|
ITU-TG.655 |
Characteristics of a non-zero dispersion -shifted single mode fibers optical |
|
EIA/TIA598 B |
Col code of fiber optic cables |
|
IEC 60794-4-10 |
Aerial optical cables along electrical power lines-family specification for OPGW |
|
IEC 60794-1-2 |
Optical fiber cables -part test procedures |
|
IEEE1138-2009 |
IEEE Standard for testing and performance for optical ground wire for use on electric utility power lines
|
|
IEC 61232 |
Aluminum -Clad steel wire for electrical purposes |
|
IEC60104 |
Aluminum magnesium silicon alloy wire for overhead line conductors |
|
IEC 61089 |
Round wire concentric lay overhead electrical stranded conductors . |
Typical design for Double Layer:
|
Specification |
Fiber Count |
Diameter(mm) |
Weight (kg/km) |
RTS(KN) |
Short Circuit (KA2s) |
|
OPGW-96[121.7;42.2] |
12 |
13 |
671 |
121.7 |
42.2 |
|
OPGW-127[141.0;87.9] |
24 |
15 |
825 |
141 |
87.9 |
|
OPGW-127[77.8;128.0] |
24 |
15 |
547 |
77.8 |
128 |
|
OPGW-145(121.0;132.2) |
28 |
16 |
857 |
121 |
132.2 |
|
OPGW-163(138.2;183.6) |
36 |
17 |
910 |
138.2 |
186.3 |
|
OPGW-163(99.9;213.7) |
36 |
17 |
694 |
99.9 |
213.7 |
|
OPGW-183(109.7;268.7) |
48 |
18 |
775 |
109.7 |
268.7 |
|
OPGW-183(118.4;261.6) |
48 |
18 |
895 |
118.4 |
261.6 |
Note:
1. Only a part of OPGW cables are listed in the table. Cables with other specifications can be inquired.
2. Cables can be supplied with a range of single mode or multimode fibers.
3. Specially designed Cable structure is available on request.
MORE PRODUCT
Certification
PAKING AND SHIPPING
|
1. Standard Packaging: Rolled by wooden wooden drums. 2000m to 6000m/drum or other required. 2. Sheath mark: The following printing(white hot foil indentation)is applied at 1meter intervals. a. Supplier: Guanglian or as customer required b. Standard Code(Product Type, Fiber Type, Fiber Count) c. Year of manufacture: 7 years d. Length marking in meters. |
Our Service:
1.We are the one of biggest manufacture of fiber optic cable in China and has more than 10 years manufacturing and selling experience. 2.We accept OEM. The cable size and material are customized. Ur own logo and own design are welcome. We will produce according to your requirment and description; 3.Please send us inquiry for more products info and we will give you feedback in 12 hours. |
FAQ
1.Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.
2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.
5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.
