OPGW OPGW GL Fibra Optica Aluminum Opgw
- T/T Credit Card
You May Like
-
OPGW Opgw GL Fibra Optica High Quality Opgw
-
GL Fiber Optic Cable Opgw Fiber Optic G655/g652d/g657a1/a2
-
GL Fibra Optica PBT OPGW
-
GL Fio de Fibra Optica Opgw Fiber Cable Aluminum PBT Tube OPGW
-
GL Fibre Optic Cable Opgw de Sevicio Fibra Opotica Central AL-Covered Stainless Steel Tube Single Or Double OPGW
-
GL Fibre Optic Cable Opgw de Sevicio Fibra Opotica 24/28/36/48/96 Core Opgw
Product Description
GL fio de fibra optica opgw 12core fiber cable box12core multimode fiber cablefiber optic m3 cable 16core
Description:
The central stainless steel tube is surrounded by single or double layers of aluminum clad steel wires(ACS) or mix ACS wires and aluminum alloy wires. are the most widely used cables ,their design is fully adapted to the most common electric line needs.
Characteristic:
1. High quality standards for designing, testing and producing with grade A materials available to ensure long-term reliability .
2. Engineering support supervising and providing its own line of accessories hardware .
3.Seal stainless steel tube superior protection to the fiber optical to moisture and extreme environmental conditions such as lightening
4. To construct OPGW must cut power, resulting in greater loss, thus OPGW must be used in constructing high pressure line over 110kv;
5. Apply to the transformation of old lines.
Standards:
|
ITU-TG.652 |
Characteristics of a single mode optical fiber |
|
ITU-TG.655 |
Characteristics of a non-zero dispersion -shifted single mode fibers optical |
|
EIA/TIA598 B |
Col code of fiber optic cables |
|
IEC 60794-4-10 |
Aerial optical cables along electrical power lines-family specification for OPGW |
|
IEC 60794-1-2 |
Optical fiber cables -part test procedures |
|
IEEE1138-2009 |
IEEE Standard for testing and performance for optical ground wire for use on electric utility power lines
|
|
IEC 61232 |
Aluminum -Clad steel wire for electrical purposes |
|
IEC60104 |
Aluminum magnesium silicon alloy wire for overhead line conductors |
|
IEC 61089 |
Round wire concentric lay overhead electrical stranded conductors . |
Typical design for Double Layer:
|
Specification |
Fiber Count |
Diameter(mm) |
Weight (kg/km) |
RTS(KN) |
Short Circuit (KA2s) |
|
OPGW-96[121.7;42.2] |
12 |
13 |
671 |
121.7 |
42.2 |
|
OPGW-127[141.0;87.9] |
24 |
15 |
825 |
141 |
87.9 |
|
OPGW-127[77.8;128.0] |
24 |
15 |
547 |
77.8 |
128 |
|
OPGW-145(121.0;132.2) |
28 |
16 |
857 |
121 |
132.2 |
|
OPGW-163(138.2;183.6) |
36 |
17 |
910 |
138.2 |
186.3 |
|
OPGW-163(99.9;213.7) |
36 |
17 |
694 |
99.9 |
213.7 |
|
OPGW-183(109.7;268.7) |
48 |
18 |
775 |
109.7 |
268.7 |
|
OPGW-183(118.4;261.6) |
48 |
18 |
895 |
118.4 |
261.6 |
Note:
1. Only a part of OPGW cables are listed in the table. Cables with other specifications can be inquired.
2. Cables can be supplied with a range of single mode or multimode fibers.
3. Specially designed Cable structure is available on request.
MORE PRODUCT
Certification
PAKING AND SHIPPING
|
1. Standard Packaging: Rolled by wooden wooden drums. 2000m to 6000m/drum or other required. 2. Sheath mark: The following printing(white hot foil indentation)is applied at 1meter intervals. a. Supplier: Guanglian or as customer required b. Standard Code(Product Type, Fiber Type, Fiber Count) c. Year of manufacture: 7 years d. Length marking in meters. |
Our Service:
1.We are the one of biggest manufacture of fiber optic cable in China and has more than 10 years manufacturing and selling experience. 2.We accept OEM. The cable size and material are customized. Ur own logo and own design are welcome. We will produce according to your requirment and description; 3.Please send us inquiry for more products info and we will give you feedback in 12 hours. |
FAQ
1.Are you the real manufacturer?
Us. We are the real manufacturer with 15 year’s history.
2.What’s the MOQ?
Us. The MOQ of Fiber Optic cable is 1km.
3.What’s delivery time?
Us. The general delivery time is 5-7 days after order confirmed. It depends on the order quantity.
4.How to Store the Optical Fiber Cable Properly?
Us. Store the drum indoor before using, the drum should place sideways not on the end.
5. Can you supply customized products and logo?
Yes. We supply OEM service. You can send us your drawing.
6.What’s your payment terms?
Us. We accept T/T,L/C,Western Union,D/P etc. 30% in advance and 70% before shipment.
