Low Voltage LV Aluminum XLPE Overhead ABC Amka Cable 2X16
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
-
LV Duplex Triplex Quadruplex Service Drop Bunded ABC Cable for Sale
-
Twisted LV Aluminium Conductor ABC Overhead Insulated Aerial Bundle Cable ABC Service Drop Cable Price
-
0.6/1 Kv 70mm 4 Core Underground Copper Aluminum Armoured Cable Price
-
GL Factory Price HV Cable Use for Overhead Electrical Cable Wire 10mm Copper Cable
-
26/35kv mv Cable Single Core ug Cable (cu) 95sqmm Xlpe Cable Supplier
-
0.6/1 Kv 3x95+16+70 Lv Abc Amka
Product Description
Products Description
Distribution and signal power cable for static outdoor application (with protection against direct UV-irradiation), in ground, in
water, within facilities, in cable canals, in concrete, in conditions where heavier mechanical loads and specially tensile
strains, are not expected. Used in electric power plants, transformer stations, industrial plants, metropolitan networks and in
other electric plants, same as for connection of signalling devices in industry, traffic and similar.
Specifications
art Number | Cross Section | Stranding | Approx Weight | Approx Overall Diameter | Gland Size | Single Cleat | Nom. Max. DC-resist conductor 20° C | Current rating laid direct |
(mm²) | (mm) | KG/KM | (mm) | (mm) | (Ohm/km) | (Amp) | ||
SWAPVC4X1.5 | 4 x 1.5 | 7/0.53 | 351 | 12.88 | 20s | 0.5 | 12.1 | 32 |
SWAPVC4X2.5 | 4 x 2.5 | 7/0.67 | 429 | 14.43 | 20s | 0.6 | 7.41 | 42 |
SWAPVC4X4.0 | 4 x 4.0 | 7/0.85 | 538 | 16.87 | 20 | 0.6 | 4.61 | 55 |
SWAPVC4X6.0 | 4 x 6.0 | 7/1.04 | 670 | 17.87 | 20 | 0.7 | 3.08 | 69 |
SWAPVC4X10 | 4 x 10 | 7/1.35 | 998 | 20.1 | 25 | 0.8 | 1.83 | 92 |
SWAPVC4X16 | 4 x 16 | 7/1.70 | 1,272 | 22.4 | 25 | 0.9 | 1.15 | 119 |
SWAPVC4X25 | 4 x 25 | 7/2.14 | 1,940 | 27 | 32 | 1 | 0.727 | 152 |
SWAPVC4X35 | 4 x 35 | 7/2.52 | 2,390 | 30.1 | 32 | 1.2 | 0.524 | 182 |
SWAPVC4X50 | 4 x 50 | 19/1.78 | 2,925 | 31.5 | 32 | 1.4 | 0.387 | 217 |
SWAPVC4X70 | 4 x 70 | 19/2.14 | 4,200 | 37.4 | 40 | 1.6 | 0.268 | 266 |
SWAPVC4X95 | 4 x 95 | 19/2.52 | 5,355 | 40.9 | 50s | 1.8 | 0.193 | 319 |
SWAPVC4X120 | 4 x 120 | 37/2.03 | 6,925 | 46.6 | 50 | 2 | 0.153 | 363 |
SWAPVC4X150 | 4 x 150 | 37/2.25 | 8,200 | 50.2 | 50s | 2 | 0.124 | 406 |
SWAPVC4X185 | 4 x 185 | 37/2.52 | 9,975 | 55.8 | 63s | TC9 | 0.0991 | 458 |
SWAPVC4X240 | 4 x 240 | 61/2.52 | 12,700 | 62.5 | 63 | TC10 | 0.0754 | 529 |
SWAPVC4X300 | 4 x 300 | 61/2.85 | 15,275 | 67.4 | 75s | TC11 | 0.0601 | 592 |
SWAPVC4X400 | 4 x 400 | 61/3.20 | 19,875 | 77 | 75 | TC12 | 0.047 | 667 |
Company Profile
GL Technology is a professional MV XLPE Power Unarmoured Cable (Medium Voltage XLPE Insulated Unarmoured Power Cable factory)
manufacturer and supplier in China. Our products also include AAC, AAAC, ACSR, ACAR, Galvanized Steel Wire, Aluminium Clad Steel
Wire, PVC wire, PVC/XLPE power cable, Aerial Bundled Cable, rubber cable, control cable, etc. Any Interested, Pls feel free to
email us, we will reply to you that day with feasible prices and material in time!
Wire, PVC wire, PVC/XLPE power cable, Aerial Bundled Cable, rubber cable, control cable, etc. Any Interested, Pls feel free to
email us, we will reply to you that day with feasible prices and material in time!
lso we can offer other service. Custom Merchandise:we can make cable as your need include the color ,size and so on.we also offer OEM .Complete Course Tracking:we can offer you the service from the business begin to you get the cable and use it
Cable sample : we can offer the sample free
