Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable

Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable thumbnail-1
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable thumbnail-2
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable thumbnail-3
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable thumbnail-4
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable thumbnail-5
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable photo-1
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable photo-2
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable photo-3
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable photo-4
Discounted Tester Glass Bare Fiber For 2.0mm 3.0mm FTTH Cable photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1993
Annual Export Value:
Above US$100 Million
Contact Supplier Request Quote Chat Now
Hunan Gl Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
Specification
 TESTING REPORT FOR B1.3(G652D)
Optics Specifications
Result
Attenuation(dB/km)
@1310nm
≤0.34db/km
Comply
@1383nm (after hydrogen aging)
≤0.32db/km
Comply
@1550nm
≤0.22db/km
Comply
@1625nm
≤0.24db/km
Comply
Dispersion
@1285nm~1340nm
-3.0~3.0ps/(nm*km)
Comply
@1550nm
≤18ps/(nm*km)
Comply
@1625nm
≤22ps/(nm*km)
Comply
Zero-Dispersion wavelength
1300~1324nm
Zero-Dispersion slope
≤0.092ps/(nm2*km)
Mode field diameter @ 1310nm
9.2±0.4μm
Mode field diameter @ 1550nm
10.4±0.8μm
PMD
Max. value for fiber on the reel
0.2ps/km 1/2
Comply
Max. Designed value for link
0.08ps/km 1/2
Comply
Cable cutoff wavelength,λ cc
≤1260nm
Comply
Effective group index(Neff)@1310nm
1.4675
Comply
Effective group index(Neff)@1550nm
1.4680
Comply
Macro-bend loss(Φ60mm,100 turns)@1550nm
≤0.05db
Comply
Back scatter characteristic(@1310nm&1550nm)
Result
Point discontinuity
≤0.05db
Comply
Attenuation uniformity
≤0.05db/km
Comply
Attenuation coefficient difference for bi-directional measurement
≤0.05db/km
Comply
Geometrical characteristics
Result
Cladding diameter
125±1μm
Comply
Cladding non-circularity
≤1%
Comply
Core/cladding concentricity error
≤0.4μm
Comply
Fiber diameter with coating(uncolored)
245±5μm
Comply
Cladding/coating concentricity error
≤12.0μm
Comply
Curl
≥4m
Comply
Mechanical characteristic
Result
Proof test
0.69GPa
Comply
Proof test
1.4N
Comply
Dynamic stress corrosion susceptibility parameter(typical value)
≥20
Comply
Environmental characteristics(@1310nm&1550nm)
Result
Temperature induced attenuation(-60~+85℃)
≤0.5dB/km
Comply
Dry heat induced attenuation(85±2℃,30days)
≤0.5dB/km
Comply
Water immersion induced attenuation(23±2℃,30days)
≤0.5dB/km
Comply
Damp heat induced attenuation(85±2℃,RH85%,30days)
≤0.5dB/km
Comply
Packing & Delivery
4pcs/carton
