Flexible 1.5mm/2.5mm solid and strand ectrical wire PVC insulated wire and cable
Application of BV electrical wire PVC insulated wire and cable
This porduct is suitable for linking the household electrical appliance,small electric tools,Instrument and power lighting devices with the rated voltage equal or less than 450/750V AC.The operation temperature of the wire is 90℃ for BV-90 and RV-90,BV-105 modle not more than 105℃,The other is 90℃.Installation temperature not lower than 0℃. standard: IEC60227 or BS ,EN,AS 25mm2, 60227 IEC,PVC Coated electric copper wire /solid conductor Housing use.
Model specification
|
Type
|
Name | Laying place and requirement | Long term working Temperature0C |
| 60227IEC01 05 BV | Copper conductor PVC insulated wires | Fixed laid indoors,conduit etc. | 70 |
| BLV | Aluminum conductor PVC insulated wires | ||
| 60227IEC07(BV-90) | Heat resistant copper conductor PVC insulated wire at 90 0C | Mainly be laid at the places of high temperature environment and can be laid indoors ,conduits. | 90 |
| BVR | Copper conductor PVC insulated flexible cable | Be for laying permanent place where flexible required. | 70 |
| 60227IEC10(BVV) | Copper conductor PVC insulated PVC sheathed round wires | Fixed laid, fit for the places with high mechanical protection and moisture place, can be laid in the air or underground. | 70 |
| BLVV | Aluminum conductor PVC insulated PVC sheathed round wires | ||
| BVVB | Copper conductor PVC insulated PVC sheathed flat wires | ||
| BLVVB | Aluminum conductor PVC insulated PVC sheathed flat wires | ||
| 60227IEC02(RV) 60227IEC06(RV) | Copper conductor PVC insulated flexible connector wire | Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required | 70 |
| 60227IEC42(RVB) | Copper conductor PVC insulated flat flexible connector wire | ||
| RVS | Copper conductor PVC insulated flexible twisting connector wire | ||
| 60227IEC52(RVV) 60227IEC53 | Copper conductor PVC insulated PVC sheathed round flexible connector wire | ||
| 60227IEC08(RV-90) | Cu conductor heat resistant PVC insulated flexible connector wire at 90 0C | Mainly used at the places where heat resistance is required | 90 |
*****************************************************************************************
Product Range:--Fiber Optic Cable (indoor/outdoor Patch cord), LAN Cable (UTP/FTP, cat5e cat6 cat7), Power Cable, Coaxial Cable (RG6 RG 59 RG11), Security Cable ( Fire Alarm Cable, CCTV camera cable RG59+power)--
