High Precision OCA Material Laminating Machine
Quick Details
| Place of Origin: | Brand Name: | Model Number: | |||
| Weight: | Certification: | Model: | |||
| Max laminating width: | Laminating temperature: | Laminating speed: | |||
| Power (AC220V 50HZ): | Machine dimension: | Manufacture experience: | |||
| Export experience: |
Packaging & Delivery
| Packaging Detail: | plywood case |
| Delivery Detail: | 15days |
Specifications
high precision oca laminator
1. Max working width: 365mm
2. Laminating thickness: Up to 5mm
3. Laminating speed: 1-5m/m
high precision oca laminator
Main Technical Parameter:
|
Model |
HX-380F |
|
Max Working Width(mm) |
365 |
|
Max Feeding Speed(m/min) |
1-5 |
|
Laminating Temperature |
70-130 degree |
|
Power |
AC220V 1.1kw/2kw |
|
Dimensions(LxWx H) |
550X605X480mm |
|
Weight (kg) |
46kg |
Features:
1. Max working width: 380mm
2. Laminating thickness: Up to 5mm
3. Laminating speed: 1-5m/min
4. Under CE and ISO certification
Functions:
1. Chromed roller with high efficient heating
2. Variable speed control
3. Proportional temperature control
4. Dual functions for single and double side lamination
Applications:
HX series laminators designed for both cold and hot lamination with compact size and low costs.
After-service:
1. Warranty for machine: 12months
2. After-service: A reply within 24 hours
3. A free training in our factory available before delivering machines
Temperature controller
Temperature controller
1. Q: Are you a manufacturer or trading company?
A:We are a manufacturer.
2. Q: Where is your factory located in? How can I visit there?
A:Our factory is located in Building 9, No. 157, Wulian Road, Yushan Town, Kunshan, Suzhou City, Jiangsu Province, China (Mainland). You can fly to Shanghai airport directly. We warmly welcome all our clients from home and abroad to visit us!
3. Q: What are your main products ?
A: Our main products are slitting machines, sheeting machines, laminating machines and Die cutting machines.
4. Q: Which industries are your machines widely used in ?
A: All industries need to cut (include full cutting and kiss-cutting), slice, laminate, rotary die cut raw materials can use our machines.
5. Q: How does your factory do regarding quality control?
A: Quality is priority. We control the quality of our products strictly, from the incoming materials to the finished products. Our factory has obtained CE & ISO Certification.
