Selling Hot Chinese Product PVC Foil Aluminum Foil Cutting Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XY One Sided Adhesive Silicon Rubber Square Cutting MachineNegotiableMOQ: 1 -
Automatic Silicon Rubber Lamination Cutting MachineNegotiableMOQ: 1
-
Automatic Hot Half Cutting Machine for Plastic Zipper PriceNegotiableMOQ: 1
-
High Speed Plastic Roll Cutting MachineNegotiableMOQ: 1
-
Automatic Rubber Mat Sheet Cutting MachineNegotiableMOQ: 1
Product Overview
Selling hot Chinese product PVC foil aluminum foil cutting machine
This machine adopts microcomputer numerical control device to set the cutting length. The model design conforms to the ergonomic
operation principle and is easy to operate. Use: This machine is suitable for cutting hook and loop fasteners, cotton yarn
tapes,elastic tapes, plastic bags, zippers, sleeves, papers, cables, metal sheets, etc.
operation principle and is easy to operate. Use: This machine is suitable for cutting hook and loop fasteners, cotton yarn
tapes,elastic tapes, plastic bags, zippers, sleeves, papers, cables, metal sheets, etc.
Details Images
Machine Parts
Name: Hot cutting blade with heating copper . Material : SKH-51
Original: Japan Lifetime : About 20 Million times cuts .
Scissor-type cutting blade, durable with highest hardness 65 HRC .Easy to adjust ,sharp ,maintain,and change .
Warranty : Nope , consumable parts are not included .
Main Features Name: Rubber Feeding roller
Material: Rubber Original: China
The rubber roll is connected with servo motor , which could feed material with high precision ,reach +/-0.1 mm .
Name: Hot cutting blade with heating copper . Material : SKH-51
Original: Japan Lifetime : About 20 Million times cuts .
Scissor-type cutting blade, durable with highest hardness 65 HRC .Easy to adjust ,sharp ,maintain,and change .
Warranty : Nope , consumable parts are not included .
Main Features Name: Rubber Feeding roller
Material: Rubber Original: China
The rubber roll is connected with servo motor , which could feed material with high precision ,reach +/-0.1 mm .
Name: Web guiding bars Material : Aluminum
Original: China
It can leads your material passing in straight way to the feeding roller ,make sure your products are in right angle .
Several strips cutting at same time are available too .
Optional part
Name: Cold cutting blade Material : SKH-51
Original: Japan
This unit can finish cold full cutting function .Scissor-type cutting blade, durable with highest hardness 65 HRC .Easy to adjust and maintain .
Original: China
It can leads your material passing in straight way to the feeding roller ,make sure your products are in right angle .
Several strips cutting at same time are available too .
Optional part
Name: Cold cutting blade Material : SKH-51
Original: Japan
This unit can finish cold full cutting function .Scissor-type cutting blade, durable with highest hardness 65 HRC .Easy to adjust and maintain .
©Taiwan Brand Servo motor & Japan brand PLC applied
©Roll to sheet cutting, max. web width 160mm
©Touch screen with the ability to save parameters
©Cutting Length adjustable, max. cutting length can be customized
©Cutting tolerance can be +/-0.1mm based on materials.
©Cutting edge can be sealed perfectly without any burrs.
©Cutting temperature(max. temperature 680℃) can be adjustable based on different materials.
©Cutting length and cutting speed adjustable.
©Roll to sheet cutting, max. web width 160mm
©Touch screen with the ability to save parameters
©Cutting Length adjustable, max. cutting length can be customized
©Cutting tolerance can be +/-0.1mm based on materials.
©Cutting edge can be sealed perfectly without any burrs.
©Cutting temperature(max. temperature 680℃) can be adjustable based on different materials.
©Cutting length and cutting speed adjustable.
every detail is strictly for your conveniencetrust more because of quality
01 computer control
use microcomputer numerical control device to set cutting length
02 reasonable design
model design accords with ergonomic operation principle
01 computer control
use microcomputer numerical control device to set cutting length
02 reasonable design
model design accords with ergonomic operation principle
03 easy to operate
the machine adopts fully automatic design, convenient and time saving
04 flexible control
the cutting knife is attached with a heating device,which can heat and consolidate the webbing incision without generating burrs
the machine adopts fully automatic design, convenient and time saving
04 flexible control
the cutting knife is attached with a heating device,which can heat and consolidate the webbing incision without generating burrs
PRODUCT SPECIFICATIONS
Model |
HX-160 |
Voltage |
220V |
Power |
1/2HP |
N.W. |
88kg |
GW. |
138kg |
Cutting Length |
0.1-9999.9mm |
Cutting Width |
1~160mm |
Measurement |
550x550x1000mm |
PRODUCT CONFIGURATION
plc
160mm cold knife
160mm hot knife
Customer Machine
PLC Control Pneumatic Flexible Flat Cable Cutting Machine
Automatic Cutting Machine for Leather Wire Nylon Woven Elastic Belt
Sample
Our company
We are a team of industry professionals with strong backgrounds in cutting, die cutting, slitting, laminating
and rolling. Other related machines in our fields can be customized based on your specific requirements.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near
Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train.
Established in 2007, we have been dedicated on converting machines which are used before and after
printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers
reliable products, perfect service.Our products are widely applied in laminating, slitting and die cutting
for shield materials, sticky materials, insulating materials, conductive materials, electronic materials.
Sizing cutting for strings, belts, rolls in bag line, shoe and cap line and plastic and rubber line.
and rolling. Other related machines in our fields can be customized based on your specific requirements.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near
Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train.
Established in 2007, we have been dedicated on converting machines which are used before and after
printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers
reliable products, perfect service.Our products are widely applied in laminating, slitting and die cutting
for shield materials, sticky materials, insulating materials, conductive materials, electronic materials.
Sizing cutting for strings, belts, rolls in bag line, shoe and cap line and plastic and rubber line.
