High Precision Rolling To Sheet Automatic Label Sticker Cutting Machine
Working video:
/v_show/id_XODE5MzQzNjky.html ( HX-360GD high speed)
/v_show/id_XNDgyMDQ0ODgw.html ( HX-360D)
Functions:
This machine employs a man-machine + PLC system equipped with a pneumatic device, adding import photoelectricity eyes and suck device, to avoid accumulative error. marking and cutting, Which will improve cutting efficiency, High precision, low loss, easy operation.
Application:
Sizing cutting for printed material, conductive fabric, foam, diffuser, reflector film, double-sided adhesive tape, nickel plate, PET, PC, PE insulation paper copper /aluminum foil and all kinds of adhesive tapes.
Main technical parameters:
|
Model |
HX-360D |
|
Voltage |
220/380V |
|
Power |
1HP |
|
N.W. |
260kg |
|
GW. |
280kg |
|
Cutting Length |
0.1~9999.9mm |
|
Cutting Width |
1~360mm |
|
Measurement |
780x920x1070mm |
Features:
1. The max width: 360mm
2. Tolerance: 0.05mm, Precision: 0.1mm
3. Material thickness: 0.5mm-15mm
4. Kiss cut or cut through available
5. Under CE and ISO Certifications
6. Warranty for the machine: 12months
7. Delivery time: 1-3days
8. Cut through for standard machine
9. Kiss cut is for optional
Characteristics:
1. This machine employs a man-machine interface + PLC system equipped with pneumatic pushing device.
2. For half cutoff with multi-cut, full cutoff with one-cut.
3. Five different cutting length can be set.
4. Different cutting quantity and circulation time also can be set to improve cutting efficiency.
5. The cutting length is accurate.
6. The operation is easy.
7. The waste rate is low.
8. Manufacturing experience: 30 years
9. Export experience: 20 years
After-service:
1. Warranty for machines is 12 months
2. A promptly reply within 24 hours
3. Free usage training before delivering machines in the factory
Kunshan Hexin Precision Company is a collection of produciton,research and development, sales and service as one fo professional electronic machinery manufacturing enterprises. We specialized in microcomputer slicing machines, cutting machines, slitting machines, laminating machines and die-cutting machines for many years. Our company has obtained 11 patents and passed the SGS factory qualification certification and the European Union CE certification. In 2013, we have got "national high-tech enterprise/" Our products are exported to Europe, America, Southeast Asia, the Middle East, Singapore, India, Thailand agents at abroad, our products enjoy a good reputation at the domestic and international market.
1. We are a factory, and the price is favorable.
2. We have strict QC system.
3. We offer a free after-sales service for one year. Product warranty time is 1 year.
4. Our engineers are available to service machinery overseas.
5. Our machines have been sold to over 40 countries.
6. Strictly package
